Home > Products > Hydraulic System For Concrete Mixer > Hydraulic Planetary Gearboxes
Hydraulic Planetary Gearboxes
- 100 Set / Sets per Month
- Qingdao
Product Details
Gearing Arrangement: | Planetary | Output Torque: | 25000N.m | Input Speed: | 800r/min |
Place of Origin: | Shandong, China | Model Number: | HLMC-30/55/70 | Brand Name: | Highland |
Packaging Details
in wooden case
Product Description
Specifications
1.Max. input speed 2500rpm2.output torque 42000Nm -72000Nm
3.Good performance, low noise
4.One year warranty
Applications:
Concrete mixer truck
IDM reducer ( concrete tank dedicated )
IDM concrete mixer truck dedicated reducer world number more than 80,000 sets of marketing has become the preferred mixer manufacturers supporting
IDM reducer torque , low noise
IDM reducer gears and shafts used are immersed in an oil bath , continuous operation can have a maximum service life and minimum wear and tear
IDM reducer is a world famous and most experienced drive shaft and gear manufacturers produce
IDM reducer easy to install, simple to maintain , beautiful appearance
Products suitable conditions :
Good concrete trucks ( tank ) of the drive means , and an output terminal of the other requires a certain swing where
Adapt to conditions -30 °C -45 °C field work conditions
Input speed is less than 2500rpm
Output torque 15000-75000N.m, for 3m3 to 16 m3 of concrete mixer truck
You can forward and reverse operation , duty cycle is less than 40%
IDM Gearbox Technical Specifications
Model | Reduction Ratio | Max Torque N.m | Limited Torque N.m | Max Speed r/min | Applicable models | Mounting Angle | Swing Angle |
HLMO-20 | 50 36 | 15000 | 20000 | 800 | 3-4m3 | 16° | ±6° |
HLMO-30 | 54 | 25000 | 30000 | 800 | 5m3 | 16° | ±6° |
HLMO-40 | 54 | 30000 | 38000 | 800 | 6-8m3 | 16° | ±6° |
HLMO-50 | 31.5 45 | 38000 | 48000 | 800 | 6-9m3 | 15° | ±6° |
|
|
|
|
|
|
|
|
HLMC-30 | 141 | 25000 | 30000 | 2500 | 3-5m3 | 15° | ±6° |
|
|
|
|
|
|
|
|
HLMC-55 | 141 | 48000 | 54000 | 2500 | 6-8m3 | 15° | ±6° |
HLMC-70 | 141 | 60000 | 72000 | 2500 | 10-12m3 | 15° | ±6° |
HLMC-80 | 141 | 75000 | 80000 | 2500 | 12-16m3 | 15° | ±6° |
Company Profile
Profile
Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing.
Hydraulic Pump
Hydraulic Comprehensive Test Bench
Digital Hydraulic Test Bench
MYHT Portable Hydraulic Tester
Hydraulic Pump Parts
Service: On-site technical advisory for Hydraulic System
Maintenance: Hydraulic Pump or Motor imported or made in China
Jinan High Land Hydraulic Pump Co.,Ltd.
Address:N0.26, Beiyuan Street, Licheng District, Jinan
Tel: 0086-0531-88796130 88770136
Fax: 0086-0531-88796120
Technical Support: 13805406089
Post Code: 250100
Hydraulic Digital Test Bench
Maintenance and test equipment for testing Hydraulic Pump, Motor
Parameters:
Flow: 300-500L/Min
Pressure:35Mpa
Power: 75-250KW
Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive
Portable Hydraulic Tester
MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China.
Potent No.: ZL 2005 2 0080054.X
Parameters:
Flow: 200---800L/Min.
Precision:1%
Pressure: 420bar
Temperature:150
Weight: 6.2-10.5kg
Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester
Service: on-site technical advisory for hydraulic system, system reform, parts test
Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
