Specifications
MYHT-1-4 Portable Hydraulic Tester1.One year warranty
2.Testing hydraulic pumps, valves, cylinder flow
3.3 days lead time
Portable Hydraulic Testers are a method for detecting hydraulic pumps, hydraulic motors, hydraulic valves and hydraulic system failures special instrument.
- Easy to use, the operator does not require full-time training.
-MYHT hydraulic system hydraulic tester is an ideal tool for accident prevention.
- In the case of normal operation of equipment, technicians can safely and easily accomplish online detection tasks.
- Simultaneous online measurement of flow, pressure, and temperature.
- Patent No.: ZL 2005 2 0080054.
-X traffic to 500L/min
- Pressure to 420bar
- Single, bi-directional load
Instrument features:
- Accurate measurement of flow, pressure, temperature.
- Security hydraulic oil can flow in both directions, uniaxial loading, both to protect personnel protection instruments.
- Quick hydraulic equipment, hydraulic pumps, hydraulic motors, hydraulic valves, hydraulic cylinders online test. Simple connection.
- Light Meters Light weight, small size and easy to carry. Beautifully designed, easy to clean.
- Power Meter optional 12V lithium battery can be recharged, large capacity, long life.
Technical Specifications :
model |
Max flow (LPM) |
Max pressure(bar) |
Temperature |
Precision |
Dimension(mm) |
Weight(KGS) |
MYHT-1-2 |
200 |
420 |
150°C |
±1% |
295x265x210 |
6.1 |
MYHT-1-4 |
400 |
420 |
150°C |
±1% |
295x265x210 |
8.8 |
MYHT-1-5 |
500 |
420 |
150°C |
±1% |
295x265x210 |
10.2 |
MYHT-1-7 |
800 |
420 |
150°C |
±1% |
310x285x261 |
14 |
