Specifications
1.China Country Patent2.output torque 42000Nm -72000Nm
3.One year warranty
Concrete Mixers Hydraulic Reducers
Applications:
Concrete mixer truck
IDM reducer ( concrete tank dedicated )
IDM concrete mixer truck dedicated reducer world number more than 80,000 sets of marketing has become the preferred mixer manufacturers supporting
IDM reducer torque , low noise
IDM reducer gears and shafts used are immersed in an oil bath , continuous operation can have a maximum service life and minimum wear and tear
IDM reducer is a world famous and most experienced drive shaft and gear manufacturers produce
IDM reducer easy to install, simple to maintain , beautiful appearance
Products suitable conditions :
Good concrete trucks ( tank ) of the drive means , and an output terminal of the other requires a certain swing where
Adapt to conditions -30 °C -45 °C field work conditions
Input speed is less than 2500rpm
Output torque 15000-75000N.m, for 3m3 to 16 m3 of concrete mixer truck
You can forward and reverse operation , duty cycle is less than 40%
IDM Gearbox Technical Specifications
Model |
Reduction Ratio |
Max Torque N.m |
Limited Torque N.m |
Max Speed r/min |
Applicable models |
Mounting Angle |
Swing Angle |
HLMO-20 |
50 36 |
15000 |
20000 |
800 |
3-4m3 |
16° |
±6° |
HLMO-30 |
54 |
25000 |
30000 |
800 |
5m3 |
16° |
±6° |
HLMO-40 |
54 |
30000 |
38000 |
800 |
6-8m3 |
16° |
±6° |
HLMO-50 |
31.5 45 |
38000 |
48000 |
800 |
6-9m3 |
15° |
±6° |
|
|
|
|
|
|
|
|
HLMC-30 |
141 |
25000 |
30000 |
2500 |
3-5m3 |
15° |
±6° |
|
|
|
|
|
|
|
|
HLMC-55 |
141 |
48000 |
54000 |
2500 |
6-8m3 |
15° |
±6° |
HLMC-70 |
141 |
60000 |
72000 |
2500 |
10-12m3 |
15° |
±6° |
HLMC-80 |
141 |
75000 |
80000 |
2500 |
12-16m3 |
15° |
±6° |
in wooden case by air or by sea
Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing.
Hydraulic Pump
Hydraulic Comprehensive Test Bench
Digital Hydraulic Test Bench
MYHT Portable Hydraulic Tester
Hydraulic Pump Parts
