ITC VA-6000RC EN54-16 Voice Evacuation System Recorder

ITC VA-6000RC EN54-16 Voice Evacuation System Recorder

VA-6000 RC shall be used for working with main controlling system to record calling content of Mic , which  provides a scientific basis for the subsequent accident responsibility, and provides two control methods of both CAN trunk protocol and relay contact; Audio files are stored in SD card and the max  memory space will be 32G.

ITC VA-6000RC EN54-16 Voice Evacuation System Recorder

1.  Supporting long time, loop recording, automatically overwriting the oldest audio file when there is no storage space.

2.  Supporting two control methods of both CAN trunk and relay contact

3.  External storage, convenient file accessing;

4.  SD card connection state detection

5.  The recording files can play by ordinary player and no need professional players

ITC VA-6000RC EN54-16 Voice Evacuation System Recorder

*One recording audio input; Receiving audio recording from VA – 6000MA and keeping into the SD card; it can recordcyclically for a long time and cover the recording file automatically

* VA-6000MA controls the recorder to start or end the record by CAN trunk or the external short circuit or without voltage signal.

*Backup DC24V power input; can driveled by DC 24V power provide by VA-6000BC

ITC VA-6000RC EN54-16 Voice Evacuation System Recorder

ITC VA-6000RC EN54-16 Voice Evacuation System Recorder

1——19 inch rack positioning hole

2——:main power indicator

1,Green-main power supply Normal

2,Yellow- main power supply malfunction

3——Spare DC 24V power indicator

1,Green—spare power supply normal

2,Yellow—cannot detect spare power

4—Device recording state indicator

1,Green-- in the recording mode

2,yellow—out of recording mode

5——SD cards connection state indicator

1,Green- connection on

2,Yellow- connection off

ITC VA-6000RC EN54-16 Voice Evacuation System Recorder

1——Equipment connector

2——(>=0.5S);relay contact control interface

3—SD cards outlet

4——Record audio input

5——Spare 24V power input connector

6——power switch

7——AC220V power outlet

8——Attention: Be sure that this );Device earth terminal
