ITC VA-P120 Series Modular Design High Effectiency Evacuation Alarm Class D Power Amplifier

ITC VA-P120 Series Modular Design High Effectiency Evacuation Alarm Class D Power Amplifier photo-1
ITC VA-P120 Series Modular Design High Effectiency Evacuation Alarm Class D Power Amplifier photo-2
ITC VA-P120 Series Modular Design High Effectiency Evacuation Alarm Class D Power Amplifier photo-3
US$ 350 - 800 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
ITC
Model Number:
VA-P120 VA-P240 VA-P350 VA-P500
Type:
Professional Amplifier
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Brand Name ITC
Model Number VA-P120 VA-P240 VA-P350 VA-P500
Type Professional Amplifier
Channels 1
Place of Origin Guangdong, China
Product Description

ITC VA-P120 Series Modular Design High Effectiency Evacuation Alarm Class D Power Amplifier

This series sound power amplifier is used in ITC Voice Alarm Evacuation System; 4 mutually independent power amplifiers with PFC module, power-saving control module and DC 24V power interface are integrated in 2U case, and the Max power is up to 500W. optional rated power includes 120W, 240W, 350W and 500W;

Features

ITC VA-P120 Series Modular Design High Effectiency Evacuation Alarm Class D Power Amplifier

1) Using modular design, which could be configured according to the demand;

2) Adopt design proposal of high-efficient class D digital amplifier, which helps with less power consumption;

3) In 2U case, 4 mutually independent channels, and the Max power of each channel is up to 500W power.

Basic Function

ITC VA-P120 Series Modular Design High Effectiency Evacuation Alarm Class D Power Amplifier

1)  Protection for over-loaded and short;

2)  Automatic temp-control;

3) Automatic working status detection for each channel amplifier and the report would be sent to VA-6000MA;

4)  With LED indicators to display status;

5)  Automatic switching between main amplifier and backup amplifier; automatic status detection for speaker loop;

6)  Support 3-wire cabling.

Technical Parameter
Model
VA-P120
VA-P240
VA-P350
VA-P500
AC Power Supply
Power supply
AC 220V to AC 240V, 50Hz/60Hz
Working Current
0.7A
1.4A
2A
2.8A
DC Power Supply
Power supply
DC 24V; ±20%
Working Current
6.5A
12.3A
18A
25A
Rated Power
120W
240W
350W
500W
Power Consumption
150W
295W
425W
605W
Audio Parameters
Input Method
385mV, balanced
Frequency Response
40Hz to 20KHz, ±3dB
Speaker Output
Constant voltage at 100V
Distortion
≤1% at rated power, 1KHz
SNR
≤80dB
Working Temperature
5℃ - 40℃
Relative Humidity
<95%
Cooling Method
Air cooling
Protection
Delay, overheat, short and overload
Dimension (WxHxD)
478x88x484mm
Weight
11Kg
