Hydraulic Pump and Systems Test Bench and Test Stand

Name: Hydraulic Pump and Systems Test Bench and Test Stand
Brand: High Land
Availability: InStock

FOB Price

US$ 10,000 - 30,000 / Unit

1 Unit(Min. Order)

Port Qingdao

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	High Land
Model Number	YST380/500	Theory	Rotary Pump
Structure	Piston Pump	Usage	Oil
Power	Hydraulic	Standard or Nonstandard	Standard
Fuel	Gasoline	Pressure	High Pressure
Application	Other, Construction machinery

Packaging Details

According to the customers

Product Description

Specifications

Hydraulic Test Stand And Test Table
Hydraulic Pump Test Bench
Hydraulic Motor test rig

        Hydraulic test stand (hydraulic test stand, hydraulic test bench) according to customer needs, design and manufacturing into a comprehensive test-bed: hydraulic component test stand. Or test stand design and manufacturing into a single function: hydraulic pump test bench, test rig of the hydraulic motor, hydraulic valve test bench, cylinder test bench. Can also be designed and manufactured in accordance with the special needs of the industry, such as digging machine hydraulic test rig, hydraulic hammer test bench. Users can also choose a variety of configurations, such as proportional control system, digital display system frequency control system and computer monitoring and control system.
    Comprehensive test bench for hydraulic components for hydraulic pumps, hydraulic motors, hydraulic valves, hydraulic cylinders, performance testing, test series of hydraulic components of a variety of specifications. Comprehensive test-bed semi-closed hydraulic circuit system structure, mainly by the main hydraulic pump station, hydraulic pump station, hydraulic motor sets, sets of hydraulic cylinders, hydraulic valve sets, test machine up the oil system filter temperature control system test console oil spill recovery systems, test data acquisition system and electrical control system. The latest test standards promulgated by country or hydraulic industry factory test requirements for testing of hydraulic pumps, hydraulic motors, hydraulic valves and hydraulic cylinders. (Optional) data acquisition storage output system can generate test components performance standard test report.
    Hydraulic Test Bench YYZHSYT-75KW Main technical parameters:
    Maximum test pressure: 35MPa
    Maximum test flow: 400L/min
    Maximum test power: 75KW
    Test accuracy: ISI-B grade
    Control mode: manual or computer automatic control
    Speed range: 0 ~ 3000r/min
    Speed way: bidirectional, VVVF
    Note: otherwise 90KW, 110KW, 132KW, 160KW, 220KW, 250KW, 315KW variety of models.

Note:the test bench can be designed and manufactured in accordance with various special requirements. Please Finsh the following forms as your request,then we can give you the final offer.

Company Profile

Ji'nan High Land Hydraulic Pump Co., Ltd.

Profile Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing. Hydraulic Pump Hydraulic Comprehensive Test Bench Digital Hydraulic Test Bench MYHT Portable Hydraulic Tester Hydraulic Pump Parts Service: On-site technical advisory for Hydraulic System Maintenance: Hydraulic Pump or Motor imported or made in China Jinan High Land Hydraulic Pump Co.,Ltd. Address:N0.26, Beiyuan Street, Licheng District, Jinan Tel: 0086-0531-88796130 88770136 Fax: 0086-0531-88796120 Technical Support: 13805406089 Post Code: 250100 Hydraulic Digital Test Bench Maintenance and test equipment for testing Hydraulic Pump, Motor Parameters: Flow: 300-500L/Min Pressure:35Mpa Power: 75-250KW Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive Portable Hydraulic Tester MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China. Potent No.: ZL 2005 2 0080054.X Parameters: Flow: 200---800L/Min. Precision:1% Pressure: 420bar Temperature:150 Weight: 6.2-10.5kg Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester Service: on-site technical advisory for hydraulic system, system reform, parts test Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
