Low Price Hydraulic Motor Price
- Qingdao
You May Like
Product Details
| Type | Hydraulic Motors | Model Number | MF20/21/22/23 | |
| Brand Name | Highland | Place of Origin | Shandong, China |
in wooden case
Product Description
20 Series MF20/21/22/23 Variable Hydraulic Motor 20 series mf22 hydraulic motor of Mixers Trucks
Mixers Trucks 20 series hydraulic motor MF23/MV23
20 Series Hydraulic Fixed Displacement Motor
Fixed displacement axial-piston motors in swashplate design are used both in closed and open circuits.
Motor rotating speed is proportional to the flow which is supplied to it. Torque produced is proportional to the hydraulic
pressure the motor receives.
Shaft direction depends on to which port (A or B) pressure is supplied. Series MFH motors are relatively compact. There is
an option of module adjustment of manifold block.
H series motors are manufactured in two variants of bodies and end caps. Except module adjustment of manifold valve,
there is an option with built-in valves to the end cap. It allows to reduce motor size.
1. Heavy duty hydraulic piston motor
2. Completely interchangeable with original
3. Widely applicable for agricultrual machinery, engineering machinery, mining machinery,industrial machinery, aviation and
transport machinery etc.
4. The hydrostatic hydraulic transmission drive in close system, consisting of PV20/21/22/23/24 serie heavy duty piston pump and motor can work continuously with pressure 21Mpa under max. speed.
5. Peak pressure of system is up to 35Mpa, and min. pressure is 0.9Mpa higher than housing pressure.
6. Max. housing working presssure is 0.28Mpa.
7. Set pressure of charging relief valve of pump and motor are respectively 1.31-1.45Mpa and 1.10-1.24Mpa higher than
housing pressure, and max. oil temperature is 80°C
Technical Parameters
| Model | Max. Displacement(ml/r) | Pressure/Mpa | Max Speed | output Power | Variable Pump | Fixed Displacement Motor | ||||
| Rated | Max | Flow at Max. Speed /(L/min) | Charge Pump Displacement /(mL/r) | Weight/kg | Torque at 10Mpa | Weight/kg | ||||
20 | 33.3 | 21 | 35 | 3800 | 8.2 | 126.5 | 8.2 | 45 | 54.1 | 27 |
21 | 51.6 | 21 | 35 | 3500 | 12.7 | 180.6 | 12.3 | 53 | 84.1 | 34 |
22 | 69.8 | 21 | 35 | 3200 | 17.2 | 223.4 | 18.0 | 61 | 114.2 | 40 |
23 | 89.0 | 21 | 35 | 2900 | 21.9 | 258.1 | 18.0 | 78 | 144.3 | 47 |
Company Profile
Profile Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing. Hydraulic Pump Hydraulic Comprehensive Test Bench Digital Hydraulic Test Bench MYHT Portable Hydraulic Tester Hydraulic Pump Parts Service: On-site technical advisory for Hydraulic System Maintenance: Hydraulic Pump or Motor imported or made in China Jinan High Land Hydraulic Pump Co.,Ltd. Address:N0.26, Beiyuan Street, Licheng District, Jinan Tel: 0086-0531-88796130 88770136 Fax: 0086-0531-88796120 Technical Support: 13805406089 Post Code: 250100 Hydraulic Digital Test Bench Maintenance and test equipment for testing Hydraulic Pump, Motor Parameters: Flow: 300-500L/Min Pressure:35Mpa Power: 75-250KW Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive Portable Hydraulic Tester MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China. Potent No.: ZL 2005 2 0080054.X Parameters: Flow: 200---800L/Min. Precision:1% Pressure: 420bar Temperature:150 Weight: 6.2-10.5kg Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester Service: on-site technical advisory for hydraulic system, system reform, parts test Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
