Home > Products > Hydraulic Motor > low noise hydraulic motor manufacturers
low noise hydraulic motor manufacturers
- 1000 Unit / Units per Month
- Qingdao
Product Details
| Place of Origin: | Shandong, China | Brand Name: | Highland | Model Number: | pv, mf |
| Theory: | Axial Flow Pump | Structure: | Piston Pump | Usage: | Oil |
| Power: | Hydraulic | Standard or Nonstandard: | Standard | Fuel: | Other, hydraulic oil |
| Pressure: | High Pressure | Application: | Other, hydraulic motor manufacturers |
Packaging Details
in Box or according to customer's request
Product Description
low noise hydraulic motor manufacturers
Technology Data:
low noise hydraulic motor manufacturers |
Models | MF20 | MF21 | MF22 | MF23 |
Max. Displacement( ml/r) | 33.3 | 51.6 | 69.8 | 89.0 |
Max. Speed( r/min) | 3590 | 3500 | 2810 | 2590 |
Out torque at 35Mpa(Nm) | 176 | 180.6 | 369 | 471 |
Rated Pressure(Mpa) | 21 | 21 | 21 | 21 |
Weight(Kg) | 30 | 34 | 40 | 47 |
Application Range:
- Paver
- Harvester
- Grain Drill
- Road Roller
- Corn Harvester
- Wheat Harvester
- Reaping Machine
- Rice Transplanter
- Concrete Mixer Truck
- Pharmaceutical Machinery
- Continous Soil Mixing Machine
- agricultural machinery
- and other heavy construction machinery
Characteristics:
1.axial pistion motor/pump
2.Static hydraulic transmission device
3.fixed displacement hydraulic piston motor
4.variable displacement hydraulic piston pump
Packing:
wooden case, suitable for long distance transportation
Shipping:
Factory:
Exhibition:
Contact us:
Company Profile
Profile
Jinan High Land Hydraulic Pump Co., Ltd. , a professional high-tech enterprise that combines hydraulic design, manufacturing and maintenance. High Land owns strong ability of R & D, first-class scientific management elites and advanced equipment for manufacturing and testing.
Hydraulic Pump
Hydraulic Comprehensive Test Bench
Digital Hydraulic Test Bench
MYHT Portable Hydraulic Tester
Hydraulic Pump Parts
Service: On-site technical advisory for Hydraulic System
Maintenance: Hydraulic Pump or Motor imported or made in China
Jinan High Land Hydraulic Pump Co.,Ltd.
Address:N0.26, Beiyuan Street, Licheng District, Jinan
Tel: 0086-0531-88796130 88770136
Fax: 0086-0531-88796120
Technical Support: 13805406089
Post Code: 250100
Hydraulic Digital Test Bench
Maintenance and test equipment for testing Hydraulic Pump, Motor
Parameters:
Flow: 300-500L/Min
Pressure:35Mpa
Power: 75-250KW
Motive Power: Hydraulic Electromotor, Frequency Conversion Electromotor, Diesel Engine Drive
Portable Hydraulic Tester
MYHT Portable Hydraulic Tester is applicable for testing flow, pressure, temperature of hydraulic system of construction equipment. It widely absorbs advanced technical experience of international peers and has filled the blank of this field in China.
Potent No.: ZL 2005 2 0080054.X
Parameters:
Flow: 200---800L/Min.
Precision:1%
Pressure: 420bar
Temperature:150
Weight: 6.2-10.5kg
Product: Hydraulic Pump, Hydraulic Comprehensive Test Bench, Digital Hydraulic Test Bench, Portable Hydraulic Tester
Service: on-site technical advisory for hydraulic system, system reform, parts test
Maintenance: Hydraulic Piston Pump, Piston Motor, Valve, Sauer Pv20,90 series RexrothA10V, A4V, A11series, Kawasaki K3V, NV series, Komatsu, CAT
Contact Us
- Ji'nan High Land Hydraulic Pump Co., Ltd.
- Contact namesummer Tang
- Phone86-531-88796130
- AddressNo. 6, Daqiao Road, Jiangjiagou Industrial Zone, Huashan Town, Licheng District
-
