Specifications
1.SG-200 manual surface metal grinder2.ISO certification
3.Taiwan head & 3 axes Taiwan leadscrews
4.Easy operation
SG-200 manual surface metal grinder
Features:
1.The machine can grind various of surfaces and complicated profiles. All the three axis feed can be finished manually, and it is especially suitable for the conditions which need no power feed.
2.The machine can grind work pieces which are made of steel,casting irons, nonferrous material. It also can be applied to grind nonmetal,such as porcelain,stone etc. The machine is used in machining workshop, repair workshop and tools workshop.
3.The machine adopts the design style"+"saddle, cross guideway is lined with TF wearable material, which makes the machine have good guidance quality and moves smoothly.
4.The column adopts double wall structure which makes the column have good rigidity. (the column of SG250 adopts steel guide-way, has higher rigidity and precision.)
5.Multiple labyrinth seal is adopted on spindle quill. It is waterproof and dustproof.
6.618A and M818A adopt manual oil pump to lubricate all moveable parts centrally. SG200 and SG250 adopt electromagnetic lubrication pump to lubricate points forcibly, and they possess smooth and stable movement.
7.The machine has high rigidity, small thermal distortion, smooth movement, little noise,high precision,convenient maintenance.
8.SG200,SG250 have higher rigidity and better stability.
| Model | Unit | M618A | M818A | SG200 | SG250 | |
| Max. width to be groud | mm | 165 | 220 | 165 | 220 | |
| Max. length to be groud | mm | 470 | 470 | 470 | 520 | |
| Max. height to be groud | mm | 350 | 350 | 350 | 350 | |
| Tabel size | mm | 155×460 | 210×450 | 150×460 | 200×520 | |
| Permanent magnetic chuck size (optional) | mm | 150×400 | 200×400 | 150×400 | 200×450 | |
| Max.longitudinal travel | mm | 500 | 500 | 500 | 570 | |
| Max.cross travel | mm | 185 | 240 | 200 | 250 | |
| Max.distance from spindle center to table surface | mm | 450 | 450 | 450 | 450 | |
| Feed of vertical handwheel | per rew. | mm | 1 | 1 | 2 | 2 |
| per div. | mm | 0.005 | 0.005 | 0.005 | 0.005 | |
| Grinding wheel size (OD×W×ID) | mm | 200×13×31.75 | 200×13×31.75 | 200×20×31.75 | 200×20×31.75 | |
| Spindle speed | r/min | 3450 (60HZ),2850 (50HZ) | ||||
| Power of spindle head | kw | Standard 1.5(build in spindle:1.1kw) | ||||
| Max.load capacity(include permanent magnetic chuck) | kg | 97 | 128 | 110 | 140 | |
| Machine weight | kg | 790 | 920 | 1000 | 1120 | |
| Machine dimension (L×W×H) | mm | 1330×1090×1680 | 1330×1150×1680 | 1360×1350×1710 | 1450×1390×1770 | |
| Package dimension (L×W×H) | mm | 1153×1373×1920 | 1153×1413×1950 | 1670×1560×1930 | 1670×1700×1980 | |
| Item NO. | 121010 | 121015 | 121011 | 121016 | ||
