M1450 Cylindrical Polishing Machine
US$ 45,000 - 55,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Cylindrical Grinding Machine
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MM2120 Inside GrinderUS$ 20,000 - 30,000MOQ: 1 Set -
MM2180 Inside Grinding MachineUS$ 20,000 - 35,000MOQ: 1 Set
-
Internal Rub MachineUS$ 20,000 - 30,000MOQ: 1 Set
-
MM2180 Internal Polishing MachineUS$ 20,000 - 35,000MOQ: 1 Set
-
MM2120 Internal Cylindrical Grinding MachineUS$ 20,000 - 30,000MOQ: 1 Set
Condition
New
Type
Cylindrical Grinding Machine
CNC or Not
Normal
Max. Grinding Diameter
500mm
Max. Grinding Length
3000mm
Place of Origin
Jiangsu, China
Brand Name
linuo
Model Number
M1450
Voltage
3phase 380V 50Hz
Power(W)
7.5kw
Dimension(L*W*H)
8100*2280*2100
Weight
17.4t
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.M1450 cylindrical polishing machine2.Cross liner guideway more efficient
3.Converter headstock & Easy operation
cylindrical polishing machine
Features:
The longitudinal movement of the worktable is driven by hydraulic or by hand wheel. The worktable can rotate to a certain degree so as to be suitable for grinding taper.
The wheel head cross feed is driven by hydraulic, which realizes automatic periodical feed and rapid feed. It can also do rough and fine feed through hand wheel.
| MAIN SPECIFICATION | UNIT | M1450 | |
| General capacity | |||
| Distance between centers | mm | 1500, 2000, 3000 | |
| Center height | mm | 270 | |
| Dia.Ground (O.D) | mm | 25-500 | |
| Dia.Ground (I.D) | mm | 30-200 | |
| Max.length ground (O.D) | mm | 1500, 2000, 3000 | |
| Max.length ground (I.D) | mm | 320 | |
| Max.weight of work piece | kg | 1000 | |
| Workhead | |||
| Swiveling angle | +90° | ||
| Center taper (MT) | MT | 6 | |
| Spindle speed | r/min | 50HZ:20-224 | |
| Wheelhead | |||
| Wheel spindle speed | r/min | 1330/665 | |
| Wheelhead rapid travel | mm | 100 | |
| Max.travel | mm | 370 | |
| Swiveling angel | -30° | ||
| Hand feed per.rev | mm | rough:4 fine:0.5 | |
| Hand feed per.gra | mm | rought:0.02 fine:0.0025 | |
| Wheel size (ODxWxID) | mm | 500x75x305 | |
| Periphearal velocity | m/s | 35/17.5 | |
| Internal grinding device | |||
| Spindle speed | r/min | 7000 | |
| Dimension of wheel | mm | max:175x32x32, min:30x25x10 | |
| Table | |||
| Hand feed per.rev | mm | 5 | |
| Max.swiveling angle of table | Clockwise | 3°(1500), 2°(2000, 3000) | |
| Anticlockwise | 6°(1500), 5°(2000), 3°(3000) | ||
| Longitudinal speed range of table | m/min | 0.1-4 | |
| Tailstock | |||
| Center taper (MT) | MT | 6 | |
| Quil travel | mm | 70 | |
| Motor | |||
| Wheelhead motor power | kw | 5/7.5 | |
| Internal grinding | kw | 1.5 | |
| Workhead motor power | kw | 4 | |
| Machine | |||
| Gross weight | kg | 11.2(1500),13(2000), 17.4(3000) | |
| Packing dimension | cm | 540x228x210, 610x228x210, 810x228x210 | |
Standard accessories:complete set of eletrical equipment, coolant equipment, wheel periphery dresser, wheel flange, wheel balancing arbor, leveling wedge, open-type steady rest, internal grinding attachment.
Optional accessories: Balance stand, Close steady rest, Radius wheel dresser, End wheel dresser, Coolant tank with magnetic seperator, coolant tank with magnetic seperator and paper filter.
