Specifications
1.Belt-driven and low noise.2. Adjustable head and cross table.
3. Milling, drilling, holes enlarging, reaming etc.
ZX7020 milling and drilling machine
Features:
Model |
ZX7020 |
ZX7016 |
Max drilling capacity (mm) |
20 |
16mm |
Max width of face milling (mm) |
50 |
50mm |
Diameter of vertical milling (mm) |
12 |
12mm |
Spindle travel (mm) |
125 |
100mm |
Spindle taper |
MT.2 |
MT.2 |
Spindle speeds (r/min) |
320, 500, 820, 1320 |
480, 800, 1400, 2400, 4100 |
Distance spindle nose to worktable(mm) |
70-375 |
5-300 |
Distance spindle axis to column(mm) |
240 |
193mm |
Worktable size(mm) |
560x200 |
500x170 |
Travel of worktable (LXW)(mm) |
280x150 |
200x90 |
Motor power |
1100W |
550W |
Outline dimension (LXWXH)(mm) |
880x700x980 |
688x700x937 |
N.W. /G.W.(kg) |
180/210 |
145/155 |
Ship measurement(mm) |
900×740×1000 |
850×660×940 |
Loading amount |
36PCS/20' container |
36PCS/20' container |
Standard accessories:
|
1. Drill bit; 2. Face milling cutter; 3. Splicing sleeve of Taper shank 4. Drift; 5. Square spanner; |
6. Inner hexagon spanner 7. Texrope (set on the machine); 8. Machine stand. |
Our Culture:
1. Our proprietary designs and exacting manufacturing specifications insure that every machine we sell meets or exceeds our customers' needs and expectations.
2. The foundation of our commitment to deliver top-quality machines to our customers is our 100% inspection Quality Control process using state-of-the-art optical measurement systems to support both manufacturing and product design.
3. We believe that this is the only way to ensure that we deliver the finest products to customers who demand precise, reliable machines in their applications.
