Specifications
1) Belt drive for low noisy;2) 12 steps of spindle speeds;
3) With milling, drilling, tapping, reaming and boring functions
ZX7032 small drilling and milling machine
Features:
Main technology information:
Max drilling capacity |
31.5mm |
Max width of face milling |
80mm |
Max tapping capacity |
12mm |
Diameter of vertical milling |
22mm |
Spindle travel |
120mm |
Spindle taper |
MT.3 |
Spindle speeds |
65,120,190,370,670,1380r/min |
Distance from spindle nose to worktable |
460mm |
Distance from spindle axis to column surface |
202.5mm |
Worktable size |
730x210mm |
Travel of worktable (LXW) |
500x175mm |
Motor power |
1500W, 910r/min |
Outline dimension (LXWXH) |
1050x1010x1100mm |
N.W. /G.W. |
310/275kg |
Ship measurement |
1050×880×1230mm |
Loading amount |
10PCS/20' container |
Standard accessories: | |
|
1. Drill bit; 2. Face milling cutter; 3. Splicing sleeve of Taper shank; 4. Drift; 5. Double-end spanner; 6. Inner hexagon spanner |
7. Texrope (set on the machine); 8. Drawbar/link; 9. Handle for headstock elevation 10. Handwheel; 11. Machine stand. |
