Home > Manufacturing & Processing Machinery > Machine Tools > Boring Machine > TC8365A Brake Drum Disc Cutting Boring Machine
TC8365A Brake Drum Disc Cutting Boring Machine
US$ 1,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Production Capacity:
15-20 Sets/month
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
T8370 T8380 Disc Drum Brake Boring Machine PriceUS$ 1,000 - 10,000MOQ: 1 Set -
Cylinder Head Reboring MachineUS$ 5,000 - 7,000MOQ: 1 Set
-
T8362 T8360A T8358A-S T8380 Brake Drum Boring MachineUS$ 1,000 - 10,000MOQ: 1 Set
-
T8018C Engine Boring MachineUS$ 8,000 - 10,000MOQ: 1 Set
-
Cylinder Head Skimming Machine for SaleUS$ 5,000 - 7,000MOQ: 1 Set
Condition
New
CNC or Not
Normal
Production Capacity
15-20 Sets/month
Place of Origin
Jiangsu, China
Brand Name
linuo
Model Number
TC8365A
Voltage
380V/50Hz/3Ph
Power(W)
1.5/0.55kw
Dimension(L*W*H)
1140*900*1600mm
Weight
1050kg
Certification
ISO9001 CE
After-sales Service Provided
Engineers available to service machinery overseas
TC8365A brake drum disc cutting boring machine
Machine specification:
Main Specifications |
Unit |
TC8365A |
Max boring diameter |
mm | 650 |
Range of Processing Diameter |
mm | 200-650 |
Spindle speed |
r/min |
25,45,80 |
Vertical travel of toolpost |
mm |
350 |
Feed |
mm/r |
0.16;0.25;0.40 |
Cross feed of tool post |
mm/r |
0.12 |
Moving speed of toopost(vertical) |
mm/min |
490 |
Main Motor Power |
kw |
1.5/0.55 |
Overall Dimensions (L x W x H) |
mm |
1140x900x1600 |
N.W |
kg |
960 |
