Herbal Essential Oil Closed Loop Extractor / Supercritical Fluid Co2 Extraction Machines
- 10 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- seamless softgel capsule machine for the beads and aroma mini ball production
- Latest AI Algorithm High Efficiency Visual Inspection Machine Equipment for Glass and PET Plastic Bottles Preforms
- Advanced High Efficiency AI Visual Quality Analyzer for Grains and Nuts Classification Grading machine
- Factory Price High Efficiency AI Visual Inspection Machine for Caps Defects Detection
- High Precision Automatic AI Vision Defect Inspection Machine for Plastic PET PP PE Bottles
- Automatic High Speed AI Visual Inspection Machine for Defects Food and Beverage Package
Product Details
Place of Origin: | Shanghai, China | Brand Name: | Chengdong | Model Number: | TH |
Application: | Other, Pharmaceutical, Foodstuff, Cosmetics, Chemical, Others | Type: | Extractor | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Herbal Essential Oil Closed Loop Extractor / Supercritical Fluid Co2 Extraction Machines
Supercritical fluid extraction(the SFE) is an application of a strong green separation technology, adopts CO2 as the solvent. Supercritical CO2 fluid under greater density and dielectric constant, the solubility of the material is large, and with the pressure and temperature changes rapidly changing, therefore, not only the solubility of certain substances selective, and easy separation of solvent and extract. Compared with conventional separation methods, has low extraction temperature strong selectivity, high efficiency, low energy consumption, no pollution and other characteristics, especially for fat-soluble, high boiling point, heat sensitive material extraction, but also for different components Fine separation. Widely used in pharmaceutical, food industry, health care products, cosmetics, perfume an other industries.
Range of Application | Type of Application |
Pharmaceutical | Extraction of effective contents of Chinese herbs; Concentration, refinement and precipitation of drug raw material; Separation and refinement of fatty mixtures |
Foodstuff | Extraction of hops; Caffeine removal from coffee berry; Refinement of vegetable oil and animal oil; Extraction of plant pigment |
Cosmetics and Perfumery | Separation and refinement of natural and synthetic perfumeries; Dealkalization of tobacco; Extraction of cosmetics raw material |
Chemical | Separation of hydrocarbon; Refinement of organic synthetic raw material; Separation of azeotrope; Retrieval of raw materials of reaction; Dehydration of water soluble chemicals of organic solution; Water oxidation |
Others | Superconducting, semiconductor, ceramics, oil washing of petroleum core, enzyme catalytic reaction, preparation of materials, superfine granules, extraction of complex compound, supercritical dyeing technique, supercritical reaction, supercritical coating technique (pharmacy-making) |
1) Low critical temperature suitable for extraction and purification of heat sensitive compound.
2) Being capable to provide inert environment to avoid oxidation of products and affection of effective content of extracts.
3) Fast extraction speed, no toxicity, non-flammable, safe application and no pollution upon environment.
4) No residue of solvent, no nitrate and ions of heavy metal.
5) The press ring of the extraction kettle can be opened quickly; O-ring is imported with service period over 4 months.
6) CO2 can be used in circulation.
7) It can be designed and manufactured as per GMP standard.
8) The pressure stabilizing system of the extraction kettle is imported back-pressure valve.
9) It can be controlled with computerized automatic control system (temperature, pressure, flow etc.)
10) All valves of the device are under special heat treatment so they are robust and durable.
Type | (L) | Max Working Pressure(Mpa) | Combination | Notes |
TH 12-1 | 1 | 40 | 1 Crafts 2 pm | Frequency |
TH22-(5+1) | 5+1 | 40 | 2 Crafts 2 pm | |
TH221-(5+1) | 5+1 | 40 | 1/2 of a column extraction | |
TH22-24x2 | 24 | 40 | 2 Crafts 2 pm | |
TH221-24x2 | 24 | 40 | 1/2 of a column extraction | |
TH22-50x2 | 50 | 40 | 2 Crafts 2 pm | Manual or computer control |
TH32-50x3 | 50 | 40 | 3 Crafts 2 pm | |
TH22-100x2 | 100 | 40 | 3 Crafts 2 pm | |
TH32-100x3 | 100 | 40 | 3 Crafts 2 pm | |
TH32-300x3 | 300 | 40 | 3 Crafts 2 pm | |
TH32-400x3 | 400 | 40 | 3 Crafts 2 pm | |
TH32-500x3 | 500 | 40 | 3 Crafts 2 pm |
We can design and manufacture combination type of small & pilot device of different extractor according to customers' requirements, design and manufacture 1000L large-scale superciritical CO2 extraction device.
