Specifications
1. ISO9001 and ISO14001 approval.2. CE passed.
3. Professional manufacturer.
4. DIN Rail mounting.
DIN Rail mounting Cam switch
DIN Rail mounting Cam switch applies to circuits of AC 50Hz with working voltage up to 440V and rated working current up to 100A. they can be provided as module operation. Also it can provided flex solution for Attached Auxiliary contacts. Usually, DW30 series Cam switch can be use as ON-OFF switch(main switch) or Emergency-off switch. and it can be upgraded to the Door Coupling Cam switch which is advisable for switchgear cabinets with hinged doors.
Below is Selection Form:
Type |
Rated Thermal Current |
No. of Poles |
PCS./CTN. |
CARTON SIZE(cm) |
DW30GS-20/3 |
20A |
3P |
76 |
49×32×31 |
DW30GS-20/4 |
4P |
76 |
49×32×31 |
|
DW30GS-32/3 |
32A |
3P |
76 |
49×32×31 |
DW30GS-32/4 |
4P |
76 |
49×32×31 |
|
DW30GS-40/3 |
40A |
3P |
68 |
49×32×31 |
DW30GS-40/4 |
4P |
68 |
49×32×31 |
|
DW30GS-63/3 |
63A |
3P |
68 |
49×32×31 |
DW30GS-63/4 |
4P |
68 |
49×32×31 |
|
DW30GS-80/3 |
80A |
3P |
50 |
49×32×31 |
DW30GS-80/4 |
4P |
36 |
49×32×31 |
|
DW30GS-100/3 |
100A |
3P |
50 |
49×32×31 |
DW30GS-100/4 |
4P |
36 |
49×32×31 |
Feature: Easy and quick mounting on DIN Rail. module type Cam switch, and can be attached Auxiliary contact on the both sides, also can be used as OFF-ON Switch or padlock device Main switch
2. Packing show
3. Company show
4. Production series
....
