Specifications
weighing sensoroverpressure protection
test the input pressure of common rail pump
compressor oil temperature control
HY-CRI200B-I Common Rail Test Bench
- Main Engine System
a) Tianqi quadrupole electric motor (380V): 15KW
Alpha frequency converter: 15KW
b) The main frame is cold box board and aviation aluminum composite structure, cast iron operating platform.
c) Its control type is automatically computer control and display by screen.
d) The accuracy of weighing oil digital readout (weighing transducer) is 0.1ml.
e) Its revolving speed range is 0~1500r/min (adjustable) (digital readout).
f) The height of main engine center is 125mm.
- Oil Circuit System
a) Fuel delivery: 10L/min
b) Fuel delivery pressure: 0~1Mpa.
c) Rail pipe is BOSCH.
d) Rail pressure: 0~200Mpa.
e) The rail pipe is controlled by automatically closed cycle, and pressure display (accuracy±0.1Mpa) with overpressure protection.
f) Oil temperature (adjustable) is controlled automatically, heated by heating pipe and refrigerated through strong refrigeration unit.
g) Its filtering type is tertiary filter.
- Electrical equipment
a) It has built-in electrical box and converter box.
b) Short-circuit protection.
- Data base
a) It has more than 600 kinds of standard build-in data, which can be upgraded.
Functions and characteristics:
1.Industrial computer , windows operating system
2.Start the test injection of common rail injector
3. Try the biggest injection of common rail injector
4. Pre-shot test the amount of common rail injector
5. Test common rail fuel injector return
6. Common rail test the uniformity of oil injector
Common Rail Injector |
Common Rail Pump |
1. Test brands: BOSCH, SIEMENS, DELPHI, and DENSO. |
1. Test brands: BOSCH, SIEMENS, DELPHI, and DENSO. |
2. Test 1-6 pieces of injectors(on request) |
2. Test the sealing of common rail pump. |
3. Test the max. Oil quantity of high-pressure common rail injector. |
3. Test the internal pressure of common rail pump. |
4. Test the cranking oil quantity of high-pressure common rail injector. |
4. Test the proportional electromagnetic valve of common rail pump. |
5. Test the backflow oil quantity of high-pressure common rail injector. |
5. Test the input pressure of common rail pump. |
6. Test the average oil quantity of high-pressure common rail injector. |
6. Test the flux of common rail pump. |
7. Set the high-pressure common rail injector's injection state and oil quantity measurement. |
7. Measure the rail pressure in real time. |
8. Data can be searched, printed and made into database. |
8. Data can be searched, printed and made into database. |
