Help CenterCRI200B-I Common Rail Fuel Injector and Pump Test Bench (checking Bosch Delphi Denso Siemens)
Related Products
-
HY-CRI-J High Pressure Common Rail Test Bench,Checking of the Sealing of Injection PumpNegotiableMOQ: 1 Set -
Professional Tools:HY-CRI-J High Pressure Common Rail Test Bench (Grafting)NegotiableMOQ: 1 Set
-
CRI200B-I Common Rail Testing EquipmentUS$ 8,000 - 12,000MOQ: 1 Set
-
HY-CRI200B-I Common Rail Test BenchNegotiableMOQ: 1 Set
-
Gold Product-HY-CRI200B-I Common Rail Systerm Test BenchNegotiableMOQ: 1 Set
Specifications
CRI200B-I common rail test bench1. Power: 15kw
2. Voltage: 380V
3. Electrical system: DELIXI
4. Tertiary filter, 5um
HY-CRI200B-I High Pressure Common Rail Injector and Pump Test Bench
ISO 9001:2008 Certificate and CE Certificate
High quality with competitive price
It is controlled by industrial computer and Windows XP.Fuel systerm is tested by sensors and displayed on LCD screen.data can be checked,stored,modified and generated into database which can be upgrade.It can test common rail injectors and pumps produced by BOSCH,DELPHI,DENSO,and Its performance is stable with high accuracy and easy to operate and maintain .
Functions and Characteristics as follows:
1.Variable frequency drive pump serves the common rail BOSCH CP3.3 pump and the maximum pressure is 200Mpa.Automatically closed-loop control,common rail pressure accuracy displyed is 0.1Mpa.
2.Adjustable injecting frequency and time.
3.Built-in standard database of common rail pump,data can be updated and added freely by users.
4.The standard database contains the waveform control data of all types o injectors,and it can output the standard waveform control signal to the injector.
5.It can test BOSCH,DENSO,and DEPHI AND SIEMNES.
6.It has industrial computer motherboard and embedded operating system window XP.
7.Operating by computer mouse and keyboard ,easy to lean and use.
8.Fuel injecting and fuel returning are automatically detected and clearly displayed on the large screen.
9.Fuel temperrature is controlled by orced cooling system.
10.Adjustable pulse width and frequency o driving signal.
11.Precise measurement ,low noise.
12.Test data report can be gennerated,stored and printed.
