Help CenterNH-YJV22 0.6/1KV XLPE Insulation Antiflaming Fire Resistant Power Cable for Sale
Related Products
-
450/750v Kvvp Control CableUS$ 10 - 101MOQ: 100 Meters -
11*0.3 Copper Core PVC Insulated and Sheathed Screen Flexible Cable (KVVP 300/300V)US$ 10 - 101MOQ: 100 Meters
-
Hot Selling KVVP/KVV Copper Conductor PVC Insulated PVC Sheathed Braid Shielding Control Cable---KVVP4x2.5mm2US$ 10 - 101MOQ: 100 Meters
-
Hot Selling KVVP/KVV Copper Conductor PVC Insulated PVC Sheathed Braid Shielding Control Cable---KVVP4x2.5mm2US$ 10 - 101MOQ: 100 Meters
-
China GOLD SUPPLIER Environment-friendly Control Cable KVVP 450/750vUS$ 10 - 101MOQ: 100 Meters
Specifications
3 conductor cable
1.XLPE Insulation 3/35kv
2.CE approvered
3.Core: 1/3
4.Section area: 25~630
Fire-resistant NH-YJV22 8.7/10KV 3X95 3 conductor cable
1.XLPE Insulation 3/35kv
2.CE approvered
3.Core: 1/3
4.Section area: 25~630
For XLPE insulated power cable ,either chemical method or physical method is employer to transform the molecular structure of PE form chain into three-dimensional network, i.e. thermoplastic PE is transformer into thermosetting XLPE. After cross-linking, the thermal and mechanical properties of PE have been greatly improved while its excellent property are still retained.
The maximum permissible operating temperature of the conductor of a XLPE insulated power cable is 90 which is higher than that of paper, PVC or PE insulated power cable. The cable has the advantage of simplicity in construction, lightness in weight, convenience in application besides its excellent electrical, thermal ,mechanical and anti-chemical corrosion properties. It can also be laid with no limitation of level difference along the route.
1. Standard
The product is manufactured according to the standard of GB12706 or IEC,BS,DIN and ICEA upon request.
2. Applications
The product is suitable for use in power transmission and distribution lines with rated power frequency voltage 3.6/kV-26/35kV
3. Operating characteristics
1, Rated power-frequency voltage Uo/U : 3.6/kV-26/35kV
2,Max.permissible continuous operating temperature of conductor: 90
3,Max.short-circuit temperature of conductor shall not exceed 250.(5s maximum duration ).
4,The ambient temperature under installation should not below 0
5, The bending radius of a single-core cable should not less than 20 times of the cable diameter. The bending radius of a three-core cable should not less than 15 times of the cable diameter.
4. Voltage designation
The rated voltage of the cable for a given application shall be suitable for the operating conditions in the system in which the cable is used , and is expressed in the form of Uo/U (Um)KV .Where :
Uo-The rated power-frequency voltage between conductor and earth or metallic scieen ,for which the cable designed;
U-The rated power-frequency voltage between conductors, for which the cable designed;
Um-The maximum value of the highest system voltagefor which the equipment may be used.
Packaging Details:Wooden drum, export standard package or as your request
Delivery Detail:Within 15days or mainly depending on your quantity
1. 22 years production experience .
2high-end Machinery and equipment for high quality cable .
3.manufacture various of cable :power cable,control cable,abc cable,submersible oil pump cable,rubber cable,elevator cable,electric cable...
4. products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL,DNV:
system ceryification:ISO9001,ISO14001,OHSAS18001
5.our product sells all over the world and has the good reputation.
fessional teamwork service for you actively.
7.quick solution and long time online time waiting for your inquiry.
8.rapid delivery and feedback.
9.we can do that you except
Motian is a brand of Sichuan Motian Cable Co., Ltd, a Chinese leader in the energy and telecom cables and systems industry.
We mainly aim at managing XLPE insulated power cables, PVC insulated power cables, plastic insulated control cables, insulated abc cable overhead cables, and stranded aluminum and ACSR. Annual product capacity of cables and wires is over 30,000 kilometers.
We obtained the certificate of ISO9001 and BV, and Cables must met the standards of China Compulsory Certification(CCC).
Motiancables and wires are widely used in the construction of buildings, airports, power transportation, urban and rural power network reformation and other main projects. Both of our products and factory are greatly commended by customers.
Now we seek for business cooperation all over the world. We sincerely welcome you to visit us.
• More than 10 Years Experience Focus On Cables & OEM manufacturing
Packaging Details:
1. In rolls or in wooden drum.
2. In export wooden pallet.
3. As per customer's requirements.
Delivery Details: 25 days for OEM, 5 days for ready goods
• Authoritative certificates supported ISO:9001, BV, CCC
