5-35kV MV cable, Copper Conductor XLPE Insulated
PVC Sheathed Power Cable
1. Rated power-frequency voltage U0/U: 450/750V, 300/500V and 300/300V.
2. Maximum permitted operating temperature of conductor is 60°C.
3. Permitted lowest working temperature is -35°C.
4. Cables can be used at places contaminated by mineral oil and fuel oil.
5. D more than 25mm
The minimum bending radius is over 6 times of cable diameter.
D not less than 25mm
The minimum bending radius is over 4 times of cable diameter.
(D-Diameter of the cable)
The specification:
Type |
Name |
Section Area(mm2) |
No. of Core |
KVV |
Copper Conductor, PVC Insulated and Sheathed control cable |
0.75 1.0 1.5 2.5 |
2-8,10,12,14,16,19,24 27,30,37 |
4.0 6.0 |
2-8,10,12,14 |
||
KVVP |
Copper Conductor, PVC Insulated and Sheathed, Copper-braid Screened Control Cable |
0.75 1.0 1.5 2.5 |
2-8,10,12,14,16,19,24 27,30,37 |
4.0 6.0 |
2-8,10,12,14 |
||
KVVP2 |
Copper Conductor, PVC Insulated and Sheathed, Copper-tape Screened Control Cable |
0.75 1.0 1.5 2.5 |
2-8,10,12,14,16,19,24 27,30,37 |
4.0 6.0 |
2-8,10,12,14 |
||
KVVP2-22 |
Copper Conductor, PVC Insulated and Sheathed, Copper-tape Screened Steel-tape armored Control Cable |
0.75 1.0 1.5 2.5 |
2-8,10,12,14,16,19,24 27,30,37 |
4.0 6.0 |
2-8,10,12,14 |
||
KVV22 |
Copper Conductor, PVC Insulated and Sheathed, Steel-tape armored Control Cable |
0.75 1.0 1.5 2.5 |
2-8,10,12,14,16,19,24 27,30,37 |
4.0 6.0 |
2-8,10,12,14 |
||
KVVR |
Copper Conductor, PVC Insulated and Sheathed, Flexible Control Cable |
0.75 1.0 1.5 2.5 |
2-8,10,12,14,16,19,24 27,30,37 |
4.0 6.0 |
2-8,10,12 14 |
||
KVVRP |
Copper Conductor, PVC Insulated and Sheathed, Braiding shielded Flexible Control Cable |
0.75 1.0 1.5 2.5 |
2-8,10,12,14,16,19,24 27,30,37 |
4.0 6.0 |
2-8,10,12,14 |
Company information:
About us
Sichuan Motian Cable Co. Ltd. was founded in 2005, located in north area of Modern Industrial Zone, Chengdu. The company has obtained ISO9001: 2008, CCC certificates and also “Sichuan Famous Brand”, “Famous and
Excellent Products in Sichuan” etc.
Our company is specialized in various cables and wires with low, medium and high voltage up to35KV
With perfect quality and sound after sales service, our products recive high popularity in domestic markets,
whatever in civil using or governrment projects. Now we are expanding our market all over the world, hereby we
sincerely welcome you to contact us and visit our company.
Product detailed:
The equipment:
Order process:
Transportation way:
1) Packing Length:100m/roll or according to client's request.
2) Inner packing: Wooden reel, plastic reel, and paper reel available.
3) Outer packing: Carton box, pull out box, pallet available.
4) Other packing available according to client's reques
Delivery Detail: 10 days after receiving 30% T/T or L/C
Our overseas sales :
The certificate:
Why Choose Motian??
- Advanced connectors & assembly cables machines and testing equipments.
- Large production capacity, short delivery.
- Strict QC checking before delivery.
- OEM/ODM service available, help you on designing.
- Prompt quotation for your inquiry.
- More than 10 years experiences in cable and wire field.
- Professional connector and cable manufacturer, with good quality and competitive price.
- Samples are available for further evaluation and you are highly welcome to visit our factory at anytime!!
