Industrial Reverse Osmosis System

Industrial Reverse Osmosis System thumbnail-1
Industrial Reverse Osmosis System photo-1
US$ 2,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Yilugao
Model Number:
DxD-500L
Contact Supplier Request Quote Chat Now
Guangzhou Yilugao Packing Machinery Technic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name Yilugao
Model Number DxD-500L

Specifications

revers osmosis system
0.5T-5 T
stainless steel

eat for deep well water, drinking water, juice water, medical water,sewage water

 Process flow

Municipal water - raw water pump - quartz sand filter - activated carbon filter -cartridge filter - reverse osmosis pure water machine - pure water



Standard

Municipal water,            Conductivity≤300us/cm

Water production≥1T/H      Pure water conductivity≤0.5us/cm



1.     Automatic Pressure Pump For Raw Water              1 Set

Flow rate:                2-3T/H

pressure:                 0.25Mpa

material:                 stainless steel

motor power:              0.55Kw





 2. Quartz Sand Filter                   1 set

Material Of Tank:               PE Twine Glass Stainless Steel Tank

Dimension(Diameter × Height):    350mm×1600mm

Process Water Volume:           2-3T/H

Filter Material:                  Quartz Sand

 3. Activated Carbon Filter                   1set

Material Of Tank:               PE Twine Glass Stainless Steel Tank

Dimension(Diameter×Height):    350mm×1600mm

Process Water Volume:          2-3T/H

Pressure:                     0.6Mpa



4. Cartridge Filter                     1 set

Material :                     Stainless Steel

Filter Cartridge:                Pp Element

Cartridge Quantity:             5

Cartridge Length:              20 Inch

Process Water Volume:           ≥2T/H



 5. RO-system maim part                           1 set

1)        High Pressure Pump             1 Set

Model:                        Vertical High-Pressure Centrifugal Pump

Flow Rate:                     2-3/H

Pressure:                       1.1~1.6 Mpa

Pump Material:                  Stainless Steel

Motor Power:                   1.5 kw

Manufacturer:                Domestic





2)        Reverse Osmosis Pressure Container       2 Pcs

Material:                           Stainless Steel

Dimension:                      106×1106mm

Pressure:                         3.0 Mpa

 (3)      Reverse Osmosis Membrane           2

   Model:                          Re4040be

   Material:                         Tfc

   Salt Rejection Rate:                ≥99.2%

   Dimension:                      100×1000mm





(4)      Flow Gauge                      2 pcs

   Measuring Range:                 0-10gpm

   Material:                         Synthetic Glass

 (5)      Conductivity Gauge                2 pcs

   Measuring Range:                 0-1000us/Cm

   Measure Mode:                   Vision
