Specifications
uncoiler, used machinesWe are specialied in making steel tile roll forming machine
Automatic steel coil uncoiler unbelievable low price
The uncoiler consists of the moving dolly, uncoiler with pressing arm, frame with lead rail, and hydraulic system.
The moving dolly can be lifted, move on the lead rail, carry the coil to the uncoiler, the leafs of the uncoiler expanse, the coil be fixed on the uncoiler, main axis of the uncoiler rotate, the coil sheet comes out.
After the coil sheet fed into the roll forming machine, the coil sheet will be pulled back to minimize the pendant.
Automatic steel coil uncoiler unbelievable low price
1. Atomatically
2. Mking and designingl kinds of roll forming machine.
3. CE, ISO, SGS , BV report
4.Top quality standard
6.Life long professional service
7.Used machines
1.Technical parameter:
For lifting dolly
Capacity: see the type of uncoiler, max. 5 tons.
Speed: 6m/ min.
Lifting: max. 5500mm.
Moving: max. 3000mm.
For decoiler
Capacity: see the type of uncoiler, max. 5tons.
Inner dia: 508mm, and 610mm (gasket is required).
Width: max. 1500mm.
Center adjust: max. 250mm.
Equipped with optical sensor, laid before decoiler, if sheet is close to sensor, it will stop
releasing coil sheet; if sheet leaves sensor, the decoiler will release coil sheet.
For hydraulic
Max. hydraulic pressure: 16 Mpa.
Motor power: 10.5 KW.
Air pressure: 0.9 Mpa.
2. Process flow:
Fix coil to the decoiler ---- fix coil sheet to lifting dolly ---- lifting dolly moves to decoiler ---
lifting dolly lifts to the same center with decoiler ---- lifting dolly moves more closely to arms
of decoiler---- expanse (coil moves to the decoiler) ---- lifting dolly returns ---- axis of
decoiler rotate (coil sheet comes out).
3. Details of the machine and panel
1.We provide the technical support for whole life of our machines
2.If buyers need the technician to go abroad , we will arrange the technician,but the buyers
should take all the cost ,inculding visa, roundtrip ticket etc.
ZheJiang Willing Technology Co., Ltd. is located in Tongxiang economic development
zone, which is about 1 hours far from Shanghai.
1. Our company
2. Production capacity
We do have a big production capacity
3. The quality control
One of our principles: we will not give customer not perfect products,absolutely.
4. Work details
5. Designed and developed
We do have the specialized design team.
6. Export market
Main Markets: South Asia,Southeast Asia,Africa,Central America,South America and so on.
7. Certificate of the company
We pursue perfectly, because of our hard work, we have obtained many honors.
For us , nothings is impossible to your willing heart.
8. Engineering samples
9. Products show
1.About after sales support
We are happy to give advice and we also have skilled technicians available across the world. We
need your machines running in order to keep your business running.
2. About our machines compare with other big companies in this market.
We are up to date with the latest technology and improve our machines accordingly
3. About our factory do regarding quality control.
Quality is priority. Every product will be fully assembled and carefully tested before it's packed for shipment.
4. About our machine?
Most of our machines are built according to customers specifications, using top brand name components.
5. About we deliver the right goods as ordered?
The core of our company culture is honesty and credit. If you check with ALIBABA, you will see that we have never got any complaint from our customers.
