high strength concrete steel floor sheet froming machine

FOB Price

USD $38,000 - $45,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port as the customer requst
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Tile Forming Machine
Tile Type	Colored Glaze Steel	Use	Wall
Production Capacity	8-10m/min	Place of Origin	Zhejiang, China
Brand Name	willing	Model Number	Roll Forming Machine
Power(W)	3+4KW	Voltage	380V 50Hz 3phases
Dimension(LWH)	750017001300	Weight	5 Tons
Certification	CE ISO	Warranty	1 Year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

steel floor desk forming machine

Steel Floor Desk Forming Machine
material	type	GI	Aluzinc steel
	thicknes(mm)	0.8-1.2	0.8-1.2
	material grade	300-500	230-300
forming speed	10-12m/min
roll material	45#stell wth chrome treatment
controller	PLC
Hydraulic system pressure	12 kw
hydraulic motor power	5.5kw
main motor power		22-30	18.5
total weight (kg)	18000		18000

Components of machine

manul uncoiler	1 set
mian roll froming machine	1 set
PLC control system	1 set
hydraulic system	1 set
cutting device	1 set
support table	2 set

1.Roller Material: high grade No.45 forged steel, Coating with hard chrome.

2.Active Shaft Material: high grade No.45 carbon wrought steel, improved the integrated

mechanic feature of the shaft.

3.Electric Elements: PLC control panel, transducer imported from Mitsubishi of Japan.

4.Other Elements: from famous suppliers in China.

5.Cutter Blade: Cr12 mould steel with quenched treatment.

Certifications

Detailed Images

5 ton hydraulic uncoiler (for option)

PLC Controller

SIEMENS or Mitsubishi for choose

^{Hydraulic station}

Motor form chinese famous factory

Our Service

Pre-Sales Service

send us your profile drawing and tell ue your requiry,

we design the machine just for you.

After-Sales Service

* 1years warranty time

* Engineers available to service machinery overseas.

Packing & Delivery

Any demand connect me!

Weichat:showna001
Whatsapp:008617757308007
Phone;008617757308007
