Deutz Engine With Silent 50kva

Deutz Engine With Silent 50kva thumbnail-1
Deutz Engine With Silent 50kva photo-1
US$ 5,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Deutz
Model Number:
TD226B-3D
Contact Supplier Request Quote Chat Now
Xiamen Huadong Machine Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Deutz
Model Number TD226B-3D
Output Type AC Three Phase
Speed 1500/1800rpm
Frequency 50/60hz
Rated Power 40kw/50kva
Rated Voltage 220v/400v
Rated Current 72A

Specifications

Diesel generator 50kva
deutz air cooled type engine with Stamford Alternator
Low fuel consumption high efficiency
TD226B-3D

 deutz engine with silent 50kva for sale 3-cylinder diesel engine deutz



Generator Deutz Features:
1. Original Detuz diesel engine
2. Radiator 40°C max,fans are driven by belt, with safety guard
3. Original Leroy Somer, Stamford, Marathon, or ENGGA alternator
4. Choice of manual/auto and AMF control panels and protection systems
5. Digital auto-start panel
6. Anti Vibration Suspension Absorber
7. Dry type air filter, fuel filter, oil filter
8. 10-hour operation base tank
9. Mould case circuit breaker
10. 24V DC start motor and storage battery
11. 24V charge alternator
12. 24V batteries, rack and cable
13. Ripple flex exhaust pipe, exhaust siphon, flange, and muffler
14. Comply with ISO and CE standards.
15. All generator sets are gone through rigorous testing before being released to the market place, including 50% load, 75% load, 100% load , 110% load and all protection function (over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)



Control Panel:
1. Automatic control panel (AMF), LCD display
2. Four protection systems
3. Emergency stop

Optional:
1. Trailer type
2. Soundproof / open type
3. ATS(automatic transfer switch)







deutz engine with silent 50kva

Controller: deepsea

deutz engine with silent 50kva                  deutz engine with silent 50kva



More Deutz diesel generator data are listed in the following

Genset model Prime power Standby power Engine model Fuel consumption g/kwh Cylinder Displacement(L) Bore*stroke(mm) Weight(kg)
kw kva kw kva
DSH30 24 30 26 33 D226B-3D 208 3L 3.12 105×120 700
DSH38 30 38 33 41 TD226B-3D 208 3L 3.12 105×120 760
DSH50 40 50 44 55 TD226B-3D 208 3L 3.12 105×120 800
DSH63 50 63 55 69 TD226B-4D 208 4L 4.16 105×120 950
DSH100 80 100 88 110 TD226B-6D 208 6L 6.23 105×120 1350
DSH125 100 125 110 138 TBD226B-6D 205 6L 6.23 105×120 1550
DSH150 120 150 132 165 TBD226B-6D5 205 6L 6.23 105×120 1380
DSH200 160 200 176 220 TBD234V6M 198 6V 10.8 128×140 2350
DSH250 200 250 220 275 TBD234V6E 198 6V 10.8 128×140 2350
DSH275 220 275 242 303 TBD234V8R 198 6V 10.8 128×140 2500
DSH313 250 313 275 344 TBD234V8U 196 8V 14.4 128×140 3250
DSH400 320 400 352 440 TBD236V8 203 8V 15.3 132×140 3400
DSH438 350 438 385 481 TBD234V12 196 12V 21.6 128×140 4900
DSH500 400 500 440 550 TBD234V12 196 12V 21.6 128×140 5300
DSH625 500 625 550 688 TBD604BL6 191 6L 26.56 170×195 5500
DSH750 600 750 660 825 TBD620L6 203 6L 26.58 170×195 6500
DSH1000 800 1000 880 1100 TBD620V8 193 8V 35.41 170×195 8500
DSH1250 1000 1250 1100 1375 TBD620V8 187 12V 53.11 170×195 10500
DSH1500 1200 1500 1320 1650 TBD620V12 187 12V 53.11 170×195 10650
DSH1875 1500 1875 1650 2063 TBD620V16 265 16V 70.88 170×195 14370



deutz engine with silent 50kva
