Home > Products > good quality generator > 576KW MTU diesel generator set
576KW MTU diesel generator set
- 100 Set / Sets per Month
- xiamen
Product Details
| Place of Origin: | Fujian, China | Brand Name: | MTU | Model Number: | THM576 |
| Output Type: | AC Three Phase | Speed: | 1500RPM | Frequency: | 50HZ |
| Rated Power: | 720/576 KVA/KW | Rated Voltage: | 400/230 V | Rated Current: | 1039A |
Product Description
Specifications
576KW MTU diesel generator1) MTU engine
2)Engga generator
3)Good quality and reasonable price
Xiamen Huadong Machine Equipment Co,Ltd
576KW MTU diesel generator set:
Engine: MTU.
Alternator:Engga,Leroy somer,Stamford,Marathon.
Control system:DSE5100,DSE5110,DSE5500G.
The following is the specification of MTU diesel generator sets:
Genset Model | Standby Power | Prime Power | Diesel Engine Model | Cylinder No Arr. | Fuel Consumption @rated Power(g/kw.h) | Dimension LxWxH(mm) | Weight (kg) | Cubic Capacity (L) | Specife Consumption Flubracation Oil (g/h) | Capacity Of Lubrication Oil (L) | Noise 1m(dba) | ||
KVA | KW | KVA | KW | ||||||||||
THM515 | 700 | 570 | 625 | 515 | 12V2000G23 | 12V | 210 | 3900x1460x1800 | 5520 | 23.88 | 1.8 | 1.05 | 90 |
THM576 | 788 | 630 | 720 | 576 | 12V2000G63 | 12V | 210 | 3900x1460x1800 | 5685 | 31.84 | 1.8 | 1.05 | 90 |
THM670 | 921 | 737 | 838 | 670 | 16V2000G23 | 16V | 208 | 4300x1770x2080 | 7000 | 31.84 | 2.2 | 1.05 | 91 |
THM814 | 1100 | 882 | 1000 | 814 | 18V2000G63 | 18V | 212 | 4600x1700x2320 | 7700 | 35.8 | 2.3 | 1.04 | 96 |
THM1000 | 1375 | 1100 | 1350 | 1000 | 12V4000G21 | 12V | 202 | 3720x1710x2360 | 9440 | 48.72 | 2.4 | 1.06 | 98 |
THM1144 | 1650 | 1264 | 1500 | 1144 | 12V4000G21 | 12V | 203 | 3870x1710x2360 | 9560 | 48.72 | 3 | 1.04 | 122 |
THM1264 | 1938 | 1390 | 1800 | 1264 | 12V4000G61 | 12V | 203 | 3960x1710x2360 | 9740 | 64.96 | 3 | 1.01 | 122 |
THM1525 | 2250 | 1678 | 2038 | 1525 | 16V4000G21 | 16V | 198 | 4550x1710x2360 | 11730 | 64.96 | 3.2 | 1.01 | 140 |
THM1688 | 2750 | 1857 | 2500 | 1688 | 16V4000G61 | 16V | 200 | 4370x1710x2360 | 12430 | 64.96 | 3.4 | 1.02 | 140 |
THM2000 | 2750 | 2200 | 2500 | 2000 | 20V4000G22 | 20V | 200 | 5500x2550x2460 | 17500 | 64.96 | 5 | 0.99 | 140 |
THM2200 | 3000 | 2400 | 2750 | 2200 | 20V4000G62 | 20V | 200 | 5600x2250x2460 | 18000 | 64.96 | 5 | 1 | 140 |
