soundproof small generator of weichai engine 40kva 50kva

Specifications

1. Soundproof small generator
2. 24v DC start motor
3. Deepsea controller
4. Super soundproof box for option

Soundproof small generator of weichai engine 40kva 50kva



Specifications of weichai diesel generator:
1. 20kw ~250kw Weichai power  generator
Weichai diesel engine is basic on the introduction of foreign(Ricardo Britain) advanced diesel engine technology and developed which is characterized by economical fuel consumption,low noise,powerful,stable operation and reliable performance.

2. Main specification
a) 3-Phase, 50Hz@1500RPM, 400/230V (Also Can Be Made According To Customers’ Special Requirements)
b) 12V/24V DC start motor and storage battery
c) Brushless, Self-excited, IP21-23, insulation class H alternator
d) 40°C radiator as standard, 50°C is optional
e) Key start panel control system as standard, digital auto-start panel is optional
f) All generator sets are gone through rigorous testing  before being released to the market place, including 50% load, 75% load, 100% load, 110% load and all protection function (overspeed stop, high water   temperature, low oil pressure, battery charging fail, emergency stop)



Accessories of diesel generator:
1) Standard accessories: Standard 40 radiator mounted on skid, Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, Standard tools kit, operation manual and document.
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.



Open type weichai diesel generator set







Weichai diesel generator set technical data

Rated power (kW/kVA)	Rated current(A)	Fuel cons.(l/h)	Engine model	Engine max output(kW)	Packing size LWH(mm)
20/25	36.2	235	495AD	26.5	2040*950*1150
24/30	43.4	233	495D	26.5	2040*950*1150
30/37.5	54.3	233	K4100D	30.1	2260*1010*1300
40/50	72.4	233	R4105D	42	2260*1010*1300
50/62.5	90.2	233	R4105ZD	56	2400*1010*1300
75/93.75	135.6	238	6105ZD	84	2890*1120*1620
100/125	181	238	6105ZLD	110	2900*1150*1650
120/150	216	238	6105AZLD	132	2900*1150*1650
150/187.5	272	238	6113ZLD	155	3200*1200*1850



Our advantage:

1. Professional team



2. Advanced technical skill



3. Factory price with good quality



4. Good after-sale-service
