Chinese Vinyl Cutter

Name: Chinese Vinyl Cutter
Brand: PCUT
SKU: 114519867

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

PCUT

Model Number:

CT630

Creation Mechanical & Electrical (Shenzhen) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name PCUT

Model Number CT630

Voltage AC220V/110V

Cache Capacity 2MB

Paper Feed Width 735MM

Cutter Pressure 0-600g

Cutting Width 630MM

Cutting Speed 500mm/s

Driver High speed stepping motor,micro-step driver

Cutting Length 20m

Repeat Cutting yes

Size 1030x275x380mm

Specifications

Brand:PCUT
Stable
Economic

Cutters plotter CT630BE

CT630

Specification:

Type	CT630BE
Media way	M form bracket Or Stand
Main board	16-bit CPU,1MB High-speed CACHE memory
Control panel	Over-head,2x8 Liquid Crystal Display,13-button touch thin-film keyboard
Driver	High speed stepping motor,micro-step driver
Max paper feed width	730mm
Max cutting width	625mm
Max cutting speed	500mm/s
Max cutting length	20000mm<=20
Max cutting thickness	1mm
Knife press	0-800g(digital adjustment)
Mechanical rssolution	0.05mm
Repeatability	<+-0.1mm
Type of tool	Carbide blade
Plotting instruction	All types Diameter 11.4mm plotter pen
Interface	USB1.0 Port and Serial Port
Power supply	AC110V/220V±10%,50Hz
Power consumption	<100VA
Operating environment	Temperature:+5~+35,relative temperature 30%~70%
Externalsize	1030x275x380mm
Transport weight	27kg
