Flexible Screw Conveyor,Spiral Conveyor
- QINGDAO SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Screw Conveyor | |
| Material | Other, Carbon steel | Material Feature | Heat Resistant | |
| Structure | Conveyor System | Place of Origin | Henan, China | |
| Brand Name | SINCOLA | Model Number | LSY | |
| Voltage | 220 - 450 V | Power(W) | 30 Kw | |
| Certification | ISO,CE,SGS | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Good performance2.Big load capacity, safe and reliable
3.According to customers' requirement
4.Muti-pitched design
Flexible Screw Conveyor,Spiral Conveyor
Applications of Cement Silo Screw conveyor
The Cement Screw conveyor are used to transfer the cement from big bags and bags to cement silo and cement batchers. Cement screws are manufactured by Sincola in different capacities and diameters by using latest technology. Sincola manufactures 2 different type of cement silos according to application ; cylindrical type and semi-open type. Sincola cement screws are drived by planetary type gearbox and appropriate engine. Sincola LSY Cement Screw Conveyorwhich have galvanized maintenance covers and special intermediate bearings, also are equipped with central lubrication system. This system is designed to provide operating convenience to our customers and is implemented in all Sincola LSY Screw Conveyor as standart. Sincola cement screws are manufactured at Ø114, Ø165, Ø219, Ø273 ve Ø323 diameters.Semi-open type cement screws are specially designed to use in Sincola MOBILE MASTER-60 mobile concrete batching plants.
Screw Conveyor Technical Parameters
Model | LSY165 | LSY219 | LSY273 | LSY325 | LSY400 | ||
DiameterΦ(mm) | 165 | 185 | 237 | 285 | 362 | ||
Outside diameterΦ(mm) | 194 | 219 | 273 | 325 | 402 | ||
Speed(r/min) | 308 | 260 | 200 | 170 | 170 | ||
Max conveying capacity(t/h) | 25 | 40 | 60 | 90 | 120 | ||
Max conveying length L(mm) | 15 | 18 | 25 | 25 | 25 | ||
Working angle(a) | 0°~60° | 0°~60° | 0°~60° | 0°~60° | 0°~60° | ||
Electric | Type | L≤9 | Y132S-4 | Y132M-4 | Y160L-6 | Y180M-4 | Y180M-4 |
Power | 5.5 | 7.5 | 11 | 18.5 | 18.5 | ||
Type | L>9 | Y132M-4 | Y160M-4 | Y180L-6 | Y180L-4 | Y180L-4 | |
Power | 7.5 | 11 | 15 | 22 | 22 | ||
Feature of Screw conveyor
The Cement Screw conveyor work is done inside the shell of closed round cross section. Screw conveyor main characteristics are the followings, compact structure, small cross-sectional area, light weight, good seal property, high transportation efficacy, smart technology layout, convenient installation, dismount and move as well as safe operation.
Company Profile
Zhengzhou Sincola Machinery Co., Ltd. is a high-technology, modern enterprise professionally engaged in the R&D and manufacturing of full automatic dry mortar plant and semi automatic dry mortar production line 1-5tph dry mortar plant and shotcrete machine plaster machine and mortar pump,wall rendering machine,concrete pump etc.
