Specifications
80 ton cement silo for sale1. Bulk cement storage silo
2. Easy loading,Easy fixed.
3. Weight:8ton
4. Long working life
Model |
Tanker Diameter |
Tanker Total Height |
Matched screw conveyor |
20Ton |
2.2m |
5.7m |
LSY163 |
30Ton |
2.4m |
7m |
LSY163 |
40Ton |
2.6m |
7.6m |
LSY163 |
50Ton |
3m |
7.6m |
LSY180 |
80Ton |
3m |
11m |
LSY180 |
100Ton |
3m |
12.5m |
LSY230 |
150Ton |
3m |
16.5m |
LSY230 |
200Ton |
4.5m |
19m |
LSY230 |
300Ton |
5.5m |
21.3m |
LSY230 |
Sincola 80 ton Sand Cement silos fly ash silo supply
80 ton Sand Cement silos fly ash silo supply Application:
80 ton Bolted Cement silos is mainly used in many areas, such as construction material, chemical engineering, energy resources, environmental protection and foodstuff, like loading and unloading plants, dosing-weighing and mixing plants, batching plant etc.
Used for:Sincola 60 ton Sand Cement silos fly ash silo is used for storing bulk materials such as grains, cement, powder, lime, gypsum, fly ash, different binder materials, gravel, limestone, sand and different chippings.
Various capacity and customized silo. The capacity of bolted-type silo ranges from 50T to 300T flexible.
All the data of silos, it considers strength of silo, resistance coefficient of the typhoon and bending resistance coefficient.
80 ton Bolted Cement silos Introduction:
We produce 80 ton Sand Cement silos fly ash silo with special and advanced technology. During construction, rolling sheet with width of 495mm is rolled to required shape from coil opening machine to forming machine and then is bended and bitten to screw embossed strip with width of 30mm-40mm around outside of steel silo. Inside steel silo, the stiffener is welded with embedded plates to improve the strength of steel silo;
Space structure technology is used in design of the silo framework to ensure the stability of big span, the angle is 25°with good strength.Equipment positioning: According to the diameter of steel silo, fixing the position of the equipments;
Rolling silo: After fixing the position of the equipments, rolling silo to 2m high;
Install silo roof: After cutting silo roof level with plasma cutter, installing the silo roof;
Lifting silo: Lifting the rolling silo to required height;
Fixing silo: Taking out the machines, fixing the silo with embedded plate;
Installing other facility: The user design and installation of the selected form object;
Will be on the loose coil winding machine loose on paper, through the coil bending machine, and the initial processing of forming the same time, the material bent in the required curvature, and then the crimping machine to bend with the good material to bite mouth, rolling forming, spiral upward through the bearing bracket lifting into the cylinder.
80 ton Bolted Cement silos accessories introduction
Sincola can provide cement silo accessories together with silo, such as screw conveyor, arch breaker device, butterfly valve, relief valve, level indicator, dust filter etc.
80ton Cement Silo Introduction Drawings
80 ton Bolted Cement silos Installation:
The installation of silos can be carried out by 3 ways.
- If the client wants to install silos by themselves, we could offer detailed instruction, and we'll give our quickest response to deal with any question in the process.
- We could also send our engineer to supervise the installation process. The client could find local workers for the installation work and our engineer will help them during the process.
- If the client needs, we could send our installation team for the whole installation issue.
Packaging & Delivery
Keywodrs: dry mortar production line,dry mortar mixing plant,dry mortar plant,dry mortar machine,dry mix mortar plant
