Home > Manufacturing & Processing Machinery > Chemical Equipment & Machinery > Chemical Drying Equipment > Longteng Rotary Kiln Wiih Advanced Techonlogy

Longteng Rotary Kiln Wiih Advanced Techonlogy

Name: Longteng Rotary Kiln Wiih Advanced Techonlogy
Brand: long Teng Series
SKU: 114427009

Longteng Rotary Kiln Wiih Advanced Techonlogy thumbnail-1

Longteng Rotary Kiln Wiih Advanced Techonlogy photo-1

US$ 160,000 - 6,000,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Rotary Drying Equipment

Place of Origin:

Shandong, China

Contact Supplier Request Quote Chat Now

Zhangqiu Long Teng Cement Machinery Making Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Rotary Drying Equipment

Place of Origin Shandong, China

Brand Name long Teng Series

Model Number Long Teng Series

Voltage 380V

Power(W) 90kw

Dimension(L*W*H) 48*3m

Weight 237tons

Certification ISO9001/CE/SGS

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Rotary Kiln
1)Environmental protection
2)Save energy
3)More safe for worker
4)Long service life

Longteng Rotary Kiln wiih Advanced Techonlogy

Product Description

1.What is Rotary Kiln?

Rotary kiln is composed of cylinder, gears, support device, kiln liner and kiln tail sealing equipment, kiln head hood and combustion. Cylinder as heated pivoting part, made of high-quality carbon steel plate.

2.Types

Rotary kiln belongs to building material equipment, and it can be divided into cement kiln, metallurgy

chemical kiln and active lime kiln, porcelain kiln according, building material kiln, calcined petroleum coke rotary kiln to different materials.

3.Rotary Kiln Features

1. Support device: advanced shaft structure, automatic temperature measuring device and electrical heating,.
2. Catch wheel: including two kinds mechanical wheel and hydraulic pressure
3. Gears: single or double. Control the rotating speed by buncher, DE machine and frequency variable motor. Be reliable, energy-saving, and efficient.
4. Cylinder tyre bolster: lower bolster has three types: fixed, zoom and floating. The structure is simple, replacement is convenient and won’t hurt cylinder.
5. Sealing equipment: there are many kinds for choice according to kiln models, including air cylinder edge sealing, spring edge sealing, and graphite block sealing and combination for above.

6. Kiln head hood: including stationary type and flexible type.

4.Working principles

The material first go into the inside drum, because there are the spiral shape boards fixed in the drum, when the rotary drum dryer make rotary working, the spiral shape board will stir the material and make the material do longitudinal movement, when the material reach the right side of the drum, under gravity effect, the material go into the second drum, because of director plate device, the material go into the second drum, and the same work principle, the material go into outside drum, in the drying working process, the material make three times drying, so the material can be dried completely.

5.Parameters

Technical paramenters of ratary kiln
Specifications	Technical parameters			main reducer		main motor			Catch wheel form	The number of support	Weight(t)
Specifications	Roller speed (r/min)	slope(%)	production(t/h)	model no	Speed ratio	model no	power (kw)	speed (r/min)	Catch wheel form	The number of support	Weight(t)
Φ1.9/1.6* 36m	0.53-1.59	4	2.5-3	JZQ750-1	48.58	JZT-72-4	30	1200/400	Mechanical	3	53
Φ2.1/1.8* 36m	0.5-1.51	4	4	UT2-110	163.36	JZS-81	30/10	1410/470	Mechanical	3	75
Φ1.2*25m	0.5-1.6	3		PM650	40.17	JZTY71-4	22	1200/120	Mechanical	3	34
Φ1.6*32m	0.158-0.258	3		PM750	48.57	JZJY61-4	15	1200/120	Mechanical	3	46.82
Φ1.8*45m	0.66-1.98	4	3.5	UT2-110	163.36	JZS-81	30/10	1410/470	Mechanical	3	80
Φ2.2*50m	0.125-1.25	3.5	4	ZS145-11	157	YCT280-4A	30	1320/132	Mechanical	3	130.71
Φ2.5*50m	0.516-1.549	3.5	5.5	ZS165-7	99.96	YCT355-4A	55	1320/440	Mechanical	3	167.5
Φ3*48m	0.3309-3.309	3.5	35	ZL130-14	32.11	ZSN4-250-21B	90	1000/100	Mechanical	3	237
Φ3.2*50m	0.398-3.975	3.5	50	ZL130-16	40.85	ZSN4-280-11B	190	1500/150	Mechanical	3	263
Φ3.3*52m	0.391-3.91	3.5	50	ZSY500-28	27.707	ZSN4-315-082	190	1000/100	Mechanical	3	280.8
Φ4*60m	0.396-3.96	3.5	104	ZSY630-35.5	34.601	ZSN4-355-092	315	1000/100	Mechanical	3	487.5
Φ4.2*60m	0.4165-4.165	3.5	116	ZSY710-35.5	35.526	ZSN4-355-12	420	1000/100	Mechanical	3	576.1
Φ4.3*62m	0.398-3.98	3.5	125	ZSY710-35.5	35.714	ZSN4-355-12	420	1000/100	Mechanical	3	5985
Φ4.8*74m	0.35-4	4	208	JH710C-SW305-40	42.226	ZSN4-400-092	630	1500/130	Mechanical	3	841

Packaging & Shipping

Our Services

Personalized Reception: Offer the full and personalized service in the whole jorney after you come to China.

Lifetime Technical Support: Offer one year of free equipment warranty and lifetime technical support

Monitor Production Progress: You can monitor production progress personally anytime after confirming the order.

Product Delivery: We have developed a long and good relationship with many shipping agents, such as APL, MSK, CSCL, MSC, etc.

Installation and Training: Send technicians to the client site for guiding the installation and adjustment, and training operators to complete the inspection and acceptance together with you.
