Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Crusher > Long Teng Roll Crusher /roller Crusher With High Energy-saving

Long Teng Roll Crusher /roller Crusher With High Energy-saving

Long Teng Roll Crusher /roller Crusher With High Energy-saving photo-1
US$ 8,099 - 12,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Roller Crusher
Application:
Mining,Quarry,chemical ,smelting,building
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Part
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Roller Crusher
Application Mining,Quarry,chemical ,smelting,building
Motor Type AC Motor
Power(W) 15*2-90*2 kw
Capacity(t/h) 5-120
Place of Origin Shandong, China
Brand Name longteng series
Model Number longteng series
Dimension(L*W*H) Showing in the parameters
Weight 4-30 TONS
Certification ISO9001/CE
Warranty one year in China mainland
After-sales Service Provided Engineers available to service machinery overseas

Specifications

roll crusher
1 Reliable operation
2 Convenient maintenance
3 ISO9001,CE
4 Energy-saving 20%

Long Teng roll crusher /roller crusher with high energy-saving

Product Description



 1.Application of roll crusher



Roll crusher Non-metal mines, Chemical industries, building materials, minerals, refractory materials, metallurgy, new material, environment protection, feedingstuff, pesticide, food and dry powdery material.



2.Principles of  roll crusher

Through the feed opening, the raw materials fall to between the two rollers, after crushed, the final products drop naturally. When there are unbreakable materials or the material is too hard, the roller will concede automatically under the effects of spring and hydraulic pressure, which will widen the clearance between the rollers and make the hard or unbreakable so as to avoid damaging the machine. The clearance between the two rollers can be adjusted to change the sizes of final products.



3.Features of roll crusher

1. Compact structure, low noise, less dust and efficient production.
2. Easy to install and only need simple foundation.
3. Can adjust the pressure and size easily.
4. Self-protection, the parts can not be damaged when hard materials such as the metals goes into the crushing cavity;
5. Low cost maintenance and easy to maintain.
6. Energy-saving, uniform size of final product.

4.Technical parameter of roller crusher

Models

Roller diameter

(mm)

Roller length(mm)

Max. Feed lump Size  (mm)

Size marker

(mm)

Capacity

(t/h)

Motor
Power

(kW)

Weight  (Kg)

Overall dimension(mm)

2PGC-400X250

400

250

≤350

15-125

20-30

11

2800

2300X1050X900

2PGC-400X500

400

500

≤350

15-125

30-50

22

3600

3000X1400X1200

2PGC-450×500

450

500

≤400

25-125

30-60

11

3800

2260X2200X766

2PGC-600×750

600

750

≤500

30-150

60-100

22

7200

2780X3065X1310

2PGC-600×900

600

900

≤500

30-150

80-120

37

7800

4500X1900X1350

2PGC-800×1050

800

1050

≤600

30-150

100-160

45

12600

2550X2050X1100

2PGC-900×900

900

900

≤700

30-200

150-200

45

13500

2780X4100X1550

2PGC-1015×760

1015

760

≤700

30-200

150-200

90

18800

7800X3200X1980

2PGC-920X1200

920

1200

<800

 20-150

 135-225

 75

16500

3848X3480X1394

2PGC-1200X1200

1200

1200

<800

 can adjust

 200

 110

 25000

8500X3000X1750

2PGC-1200X1500

1200

1500

<1000

 can adjust

 150-250

 110

 26000



Long Teng roll crusher /roller crusher with high energy-savingLong Teng roll crusher /roller crusher with high energy-saving

Long Teng roll crusher /roller crusher with high energy-saving

Packaging & Shipping



 Long Teng roll crusher /roller crusher with high energy-saving

Long Teng roll crusher /roller crusher with high energy-saving



FAQ



1>How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every machine before delivery.
2>What guarantee do you provide?
If products’ quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
3>How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.

Long Teng roll crusher /roller crusher with high energy-saving

If you are interested in our products or want to get the price. Please send email to us. We hope you can send the detail materials information, such as the specification, output, granularity and so on. This will help us make you a reasonable price and solution.
