Specifications
AS/NZS 4961 0.6/1kv Copper Neutral Screen CableCable factory since 1998
ISO9001 quality
The best prices and fast delivery
AS/NZS 4961 0.6/1kv Copper Neutral Screen Cable
CONSTRUCTION of Neutral Screen Cable
Single core
• Conductor: plain annealed copper, class 2
•Insulation:
(2.5 – 16mm2) PVC, V-90, Red
(25 – 70mm2) XLPE, X-90, Red
• Sheath: PVC V-90
• Sheath Colour: Black
Twin core
• Conductor: plain annealed copper, class 2
• Insulation:
((2.5 – 16mm²) PVC, V-90, Red, Blue
(10 – 50mm²) XLPE, X-90, Red, Blue
• Sheath: PVC V-90
• Sheath Colour: Black
3 core
• Conductor: plain annealed copper, class 2
• Insulation:
((2.5 – 16mm²) PVC, V-90, Red, Blue, White
(10 – 120mm²) XLPE, X-90, Red, Blue, White
• Sheath: PVC V-90
• Sheath Colour: Black
4 core
• Conductor: plain annealed copper, class 2
• Insulation:
((2.5 – 16mm²) PVC, V-90, Red, Blue, White, Black
(10 – 95mm²) XLPE, X-90, Red, Blue, White, Black
• Sheath: PVC V-90
• Sheath Colour: Black
