Specifications
Aluminum conductors AAC 120mm2No.wire/wire dia.:19/2.80mm
Professional manufacturer
Good quality,lowest price
Fast delivery
All Aluminum Conductors AAC 120mm2
Code Number: 120mm2.
Stranding and Wire Dia: 19/2.80mm.
Overall Dia.: 14.0mm.
Linear Mass: 322kg/km.
Max.D.C.Resistance at 20°c: 0.2459 ohm/km.
Calculated Breaking Load: 19.10kN.
Based Standard: DIN 48201.
1. Applications
AAC conductors have been widely used in power transmission lines with various voltage levels,because they have such good characteristics as simple structure,convenient installation and maintenance,low cost large transmission capacity.And they are also suitable for laying across rivers valleys and the places where special geographical features exist.
2. Service Performance
(1).The permissible long-time operating temperature for aerial conductor is 70oC.
(2).Under the circumstance that rare climate is occuring and ice coverage rate low in heavy ice area,the biggest stress of cable at the lowest point of the sag should not exceed 60% of the short-time destructive power.
(3).When connecting conductors,the conductor beside the connecting tube cant be prominent.Otherwise,the force on the operating conductors will be unbalanced.After connectors are install,the connecting tube should be painted by moisture-proof varnish in order to protect it from corrosion.
(4).Under installaion,the arc downing stress of all the conductors should be the same.With in the permissible distance of crossing buildings or dropping to the ground,the stress can be 10-15% higher than regular stress.
3. Product Performance
(1).The electrical performance of AAC is indicated in DCΩ/km (20oC).The resistivity of the hard aluminum wire for stranded wires is not greater than 28.264 nΩ. m of international standard value.
(2).The rated tensile strength of AAC is denoted with the result of total cross section of all aluminum conductors multiplied by min.tensile of corresponding size specified in the standard for aluminum wire.
4. Material Standard
Production can be arranged according to customers' requirements for material standard,etc.
