GCOM 16 port S2000B Series Best Network Switch Brands

Item

S2008B+

S2008BF

S2016B

S2016BF

S2024B

S2024BF

S2024BG

Backplane capacity

8.8Gbps

8.8Gbps

8.8Gbps

8.8Gbps

19.2Gbps

19.2Gbps

19.2Gbps

Switching capacity

3.2Gbps

3.2Gbps

3.2Gbps

3.2Gbps

9.6Gbps

9.6Gbps

9.6Gbps

Packet forwarding speed

1.19Mpps

2.38Mpps

2.38Mpps

2.38Mpps

6.55Mpps

6.55Mpps

6.55Mpps

Memory and flash

32K SDRAM memory and 512K flash

32K SDRAM memory and 512K flash

Voltage

AC:Input 176~265V,50~60Hz

AC:Input 176~265V,50~60Hz;DC:Input-36V~-72V;

Max power dissipation

Full-loaded≤7W             Idle≤5W

Full-loaded≤8W             Idle≤5W

Full-loaded≤10W               Idle≤5W

Full-loaded≤11W             Idle≤5W

Full-loaded≤12W                 Idle≤6W

Full-loaded≤13W             Idle≤6W

Full-loaded≤16W                  Idle≤6W

Outline dimensions(mm) (WxDxH)

220mmx

44mm×160mm

220mmx44mm

×160mm

220mmx44mm

×160mm

220mmx44mm

×160mm

440mmx

44mm×160mm

440mmx

44mm×160mm

440mmx

44mm×160mm

Weight (in maximum configuration)

≤2kg

≤2kg

≤2kg

≤2kg

≤3kg

≤3kg

≤3kg

Environmental requirements

Working temperature:-15C~55C:0°C~40°C                                                           Storage temperature:-40°C~70°C

Relative humidity:10%~90%,no condensing

Working temperature:-15°C~55°C

Storage temperature:-40°C~70°C

Relative humidity:10%~90%,no condensing

Item

S2008B/BF/S2016B/BF

S2024B/BF/BG

L2 feature

MAC

4K MAC address

VLAN

16 VLAN entry

802.1Q VLAN based on port

Port isolation in VLAN

26 VLAN entry

802.1Q VLAN based on port

Port isolation in VLAN

Spanning tree protocol

Loop detection

Port

Bidirectional bandwidth control

Port mirror

Security

User’s security

MAC address binds to port and port MAC address filtration

Device security

Anti-DOS attack(such as ARP,Synflood, Smurf, ICMP attack), ARP detection, worm and Msblaster worm attack

Network security

Port broadcast/multicast suppression

Self-defined packet filtration based on TCP/UDP port

Security features

QoS

Port-based super queue scheduler and self-defined flow. Each port/ flow supports 4 priority queues and scheduler of FIFS (First In First Serve), SP (Strict Priority) and WRR (Weighted Round Robin)

Multicast

IGMPv1/v2 Snooping

Reliability

Link protection

Static link aggregation

Device protection

4Kv+ lightning protection for port

2Kv+surge protection for power

Maintenance

Network maintenance

WEB-based transmit/receiving statistics for port

Device management

WEB management

Input/output configuration files

Hardware Load Default button to revert the default value

Modify device configuration by NMS to upgrade by batch

Not support
