vibratory road roller XS202J new road roller price
steering angle:±33°
operating wight:20000kg
oscillating angle:±10°
The XS202J/XS222J/XS222JE is a super heavy-duty vibratory roller with mechanical drive designed and built to offer unrivaled performance. Representing XCMG’s new generation of mechanical drive vibratory rollers, the machine sets new standards for operation, propulsion, compaction, reliability and serviceability in the industry.
Streamline Design
The large arc frame structure and streamline engine hood design make the machine novel and visually attractive in appearance. Just one look, you can be sure the machine is from XCMG.
Excellent Powertrain
The six-cylinder, direct injection, water-cooled, turbocharged Shangchai D6114ZG engine that offers high power reserve, together with the electrically controlled power box and the optional drive axle with NO-SPIN function supplies stable power transmission. The power system of XS202J can play an optimal traction performance in any cases.
Outstanding Compaction
Dual vibration frequencies and dual amplitudes satisfy different jobsite requirements. Imported heavy-duty piston pumps and motors form a closed circuit to provide enhanced durability and reliability, ensuring uniform compaction. Largest diameter drum and highest static linear load of its kind in china coupled with optimized drum structure and vibration parameters work together for outstanding compaction result and great productivity.
Reliable Electrical System
The electrical system adopts internationally sourced water-proof, dust-proof, vibration-resistant electric connectors for increased reliability.
Imported maintenance-free battery has high start-up current and good adaptability.
All-round Safety Consideration
Independently actuated caliper disc type service brakes and band type parking brakes assure safe and reliable braking.
Ant-slip handrail and stairs allow the operator to get on and off the machine freely.
During machine transportation, an articulated locking device can be used to lock the front and rear frame for safe transportation.
High Reliability
Advanced brake and clutch protection system protect the clutch and transmission against damages caused by operation mistakes.
Integrating over forty years’ experience in production, manufacturing and design, XCMG rollers have always been taking the lead in reliability in china’s roller industry.
Comfortable Operation
Electrohydraulic controlled power shift transmission and electrically controlled engine hood make operation easy. The main clutch and braking system are air actuated, offering the ease of operation.
Ergonomically designed instrument panel and simple ergonomic layout of controls minimize fatigue, making the operator highly efficient and productive.
Serviceability
Wide-opening tilt-forward engine hood can be stopped safely at any height using an electric lift device, allowing easy access to the engine for maintenance and service.
Grease fill and drain ports are easily accessible for easier daily maintenance.
Single drum , Double drum & Tyre Road Roller
1) Small size ------500kg, 800kg, 1ton, 2.5tons ,3tons, 7tons, 8tons, 10tons ,
2) Medium size -------12tons, 14tons,16tons, 17tons,18tons , 19tons,
3) Big size ----- 20tons , 21tons, 23tons, 25tons , 27tons, 28tons
|
Technical Parameters |
Item |
Unit | XS202J |
| Operating weight | kg | 20000 |
| Weight on front drum | kg | 10000 |
| Static linear load | N/cm | 470 |
| Speed range | km/h | |
| Speed I | 2.63 | |
| Speed II | 5.3 | |
| Speed III | 8.6 | |
| Theoretical gradeability | % | 30 |
| Min. external turning radius | mm | 6500 |
| Steering angle | ° | ±33 |
| Oscillating angle | ° | ±10 |
| Vibration frequency (high/low) | Hz | 33/28 |
| Nominal amplitude (high/low) | mm | 1.9/0.95 |
| Excitation force (high/low amplitude) | kN | 353/245 |
| Drum diameter | mm | 1600 |
| Drum width | mm | 2130 |
| Engine model | SC8D175.1G2B1 | |
| Rated power @2000 r/min | kW | 128 |
| Engine oil consumption | g/kW.h | 223 |
| Hydraulic oil tank capacity | L | 170 |
| Fuel tank capacity | L | 240 |
Product Photo
| Packaging Details: | container |
| Delivery Detail: | within 15 days after prepayment |
Shandong Dorson Hydraulic Co.,ltd (former name Jining Automobile Spare Parts Co.,ltd, established in 1956) which developed into private joint-stock company that specialized in producing the excavator parts including idler cushion, front idler, sprocket, track roller, carrier roller, rotary joints, hydraulic redirector, cycloid motor, one-piece multi-way valve, central rotary joints since 1998.
Shandong Dorson Hydraulic Co., ltd located in Jining City, Shandong Province —— the home town of Confucius and Mencius &the country of Courtesy. our company is a professional manufacture engaged in research &development, production and sale which founded by modern enterprise system. Covers an area of 40,000 square meters, we staff more than 200 skillful personnel including 120 with high education and equipped with advanced production,testing& inspection equipments.
Shandong Dorson Hydraulic Co., ltd adhere to the principle that“winning the market with our sincerity, meeting the challenge with our quality, broadening the market with our service” We are dedicated to revitalizing this national industry
why choose us
1. Our company started factory many years.
2. Export to over 30 countries/region, especial in whole Europe and Australia market
3. Over 200 employees work in shift ensure the punctual delivery time
4. R&D team is qualified to do customized project, OEM services
5. Inspection is carried out all through the production process
6. Export sales team is professional to serve customers, quick respond and excellent after-sales
7. Convenient and economy transportation, ship from Qingdao or Tianjin sea port of China, very convenient
8. CE & ISO9001 Certificate
9 .More easy wear spare parts will be attached with the truck crane for free
10. Our factory can do urgent order for customers with high quality if you need the crane badly
Contact us for more detailed information!
