V Type Marine Fender For Port
- 2000 Set / Sets per Month
- Any Port of China
- T/T Credit Card
- EPDM Installation Waterproof Gasket EPQ-18-5.2
- Heavy Duty Anchor Zinc Plated Anchor
- Rubber Bladder for ST Low Pressure Accumulator NXQ A-25/31.5-L-EH-S power plant spare parts
- Scraper Board, Non Excavation Accessory Horizontal Directional Drilling Rig Scraper Board, Mub Locking And Wear-resistant
- Horizontal directional drilling rig drill pipe mud blocking block, mud blocking plate
- Horizontal Directional Drilling Rig Drill Pipe Mudguard and Mud Removal Plate
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Deers | Model Number: | V / Arch |
Product Description
Specifications
1. High energy absorption and low reaction force2. High stress concentration
3. Easy replacement firm for installation
V Type Rubber Fender
Super Arch A rubber fender(SA-A)
Features:
1. High energy absorption and low reaction force
2. High stress concentration
3. Easy replacement firm for installation
4. Easy to install and change
5. Tough and reliable design
6. Wide ranges of sizes and energy capacities
7. Bolted-on UHMW PE reduce the friction factor and shear force
Specifications:
Model | B(mm) | b(mm) | c(mm) | d(mm) | H (mm) | h (mm) | S(mm) |
SA-A200H | 400 | 320 | 145 | 128 | 200 | 30 | 260 |
SA-A250H | 500 | 410 | 175 | 160 | 250 | 33 | 300 |
SA-A300H | 600 | 490 | 225 | 196 | 300 | 33 | 300 |
SA-A400H | 800 | 670 | 300 | 260 | 400 | 40 | 360 |
SA-A500H | 1000 | 840 | 375 | 325 | 500 | 45 | 420 |
SA-A600H | 1200 | 1010 | 450 | 390 | 600 | 54 | 480 |
SA-A800H | 1600 | 1340 | 600 | 520 | 800 | 72 | 640 |
SA-A1000H | 2000 | 1680 | 750 | 650 | 1000 | 90 | 640 |
Length 1000
1000L | ||||
Model | L1a(mm) | L2a(mm) | L3a(mm) | Weight(kg) |
SA-A200H-1000L | 1100 | 860 | 120 | 62 |
SA-A250H-1000L | 1125 | 865 | 130 | 85 |
SA-A300H-1000L | 1150 | 870 | 140 | 120 |
SA-A400H-1000L | 1200 | 900 | 150 | 208 |
SA-A500H-1000L | 1250 | 930 | 160 | 325 |
SA-A600H-1000L | 1300 | 960 | 170 | 480 |
SA-A800H-1000L | 1400 | 1040 | 180 | 875 |
SA-A1000H-1000L | 1500 | 1100 | 200 | 1395 |
Length 1500
1500L | ||||
Model | L1b(mm) | L2b(mm) | L3b(mm) | Weight(kg) |
SA-A200H-1500L | 1600 | 680 | 120 | 91 |
SA-A250H-1500L | 1625 | 685 | 132.5 | 130 |
SA-A300H-1500L | 1650 | 685 | 140 | 175 |
SA-A400H-1500L | 1700 | 700 | 150 | 300 |
SA-A500H-1500L | 1750 | 715 | 160 | 460 |
SA-A600H-1500L | 1800 | 730 | 170 | 680 |
SA-A800H-1500L | 1900 | 770 | 180 | 1220 |
SA-A1000H-1500L | 2000 | 800 | 200 | 1920 |
Length 2000
2000L | ||||
Model | L1c(mm) | L2c(mm) | L3c(mm) | Weight(kg) |
SA-A200H-2000L | 2100 | 620 | 120 | 122 |
SA-A250H-2000L | 2125 | 620 | 132.5 | 170 |
SA-A300H-2000L | 2150 | 625 | 137.5 | 230 |
SA-A400H-2000L | 2200 | 635 | 147.5 | 390 |
SA-A500H-2000L | 2250 | 645 | 157.5 | 605 |
SA-A600H-2000L | 2300 | 655 | 167.5 | 880 |
SA-A800H-2000L | 2400 | 680 | 180 | 1570 |
SA-A1000H-2000L | 2500 | 700 | 200 | 2450 |
Length 2500
2500L | ||||
Model | L1d(mm) | L2d(mm) | L3d(mm) | Weight(kg) |
SA-A200H-2500L | 2600 | 785 | 122.5 | 151 |
SA-A250H-2500L | 2625 | 790 | 127.5 | 225 |
SA-A300H-2500L | 2650 | 790 | 140 | 315 |
SA-A400H-2500L | 2700 | 800 | 150 | 535 |
SA-A500H-2500L | 2750 | 840 | 160 | 810 |
SA-A600H-2500L | 2800 | 820 | 170 | 1113 |
SA-A800H-2500L | 2900 | 845 | 182.5 | 2045 |
SA-A1000H-2500L | 3000 | 865 | 202.5 | 3200 |
Length 3000
3000L | ||||
Model | L1e(mm) | L2e(mm) | L3e(mm) | Weight(kg) |
SA-A200H-3000H | 3100 | 715 | 120 | 180 |
SA-A250H-3000H | 3125 | 715 | 132.5 | 270 |
SA-A300H-3000H | 3150 | 715 | 140 | 375 |
SA-A400H-3000H | 3200 | 725 | 150 | 638 |
SA-A500H-3000H | 3250 | 730 | 160 | 963 |
SA-A600H-3000H | 3300 | 740 | 170 | 1380 |
SA-A800H-3000H | 3400 | 760 | 180 | 2420 |
SA-A1000H-3000H | 3500 | 775 | 200 | 4610 |
Length 3500
3500L | ||||
Model | L1d(mm) | L2d(mm) | L3d(mm) | Weight(kg) |
SA-A200H-3500L | 3600 | 672 | 120 | 210 |
SA-A250H-3500L | 3625 | 673 | 130 | 310 |
SA-A300H-3500L | 3650 | 674 | 140 | 435 |
SA-A400H-3500L | 3700 | 680 | 150 | 740 |
SA-A500H-3500L | 3750 | 686 | 160 | 1150 |
SA-A600H-3500L | 3800 | 692 | 170 | 1595 |
SA-A800H-3500L | 3900 | 708 | 180 | 4600 |
SA-A1000H-3500L | 4000 | 720 | 200 | 6400 |
Our advantages:
Completely specifications and high level service timely for you.
Larger production capability and shorter lead time for you.
Equal quality as Trelleborg and lower price for you.
And OEM is also permitted for you.
Feel free to call ‘ 86 025 84507790 ’, our professional solution for you to solve any technical problems.
