Pressure sand filter for wastewater filtration
What is a wastewater filtration Pressure sand filter ?
JG series wastewater filtration Pressure sand filter is an ideal water purification equipment which use sand as filtration medium to remove suspended solids & undissolved impurities like dust particles & heavy metals from water to reduce turbidity.
JG series wastewater filtration Pressure sand filter use this simple but very effective method to give you the filtration you need to clean your water.
Consider to ocean transportation, JinWanTong standard wastewater filtration Pressure sand filter are available in diameter from φ800 to φ3000mm, in height from 2860 to 4480mm, these pre-engineered, pre-assembled units minimize installation and start-up costs.
As an experienced ISO9001 manufacturer started in year 2006, we provide one-stop services from project design to manufacturing, installation and final commissioning, professional services with cheap factory price for you.
Working principles of wastewater filtration Pressure sand filter :
Raw water access into wastewater filtration Pressure sand filter and is channeled to filter top, and then falls on a bed of sand. Filtered water then exits through laterals at filter bottom and the trapped dirt in the sand is removed via periodic backwashing and infrequent sand replacement.
This wastewater filtration Pressure sand filter is easy to install and much simple to maintain.
JG series wastewater filtration Pressure sand filter is typically used for:
Drinking Water Purification:
As pretreatment process before reverse osmosis system to remove suspended solids & undissolved impurities:
- Ground water purification
- Surface water purification
- Alga removal
- Grit removal
- Iron and Maganese removal
- .....
Industrial Wastewater Purification:
Mostly are used after bio-treatment process to further remove SS to reach emission standards.
Can be used for almost all kinds of industrial wastewater.
Detail specification of JG Series wastewater filtration Pressure sand filter :
| Model | JG-80 | JG-100 | JG-150 | JG-200 | JG-250 | JG-300 |
| Specification(mm) | Φ800 | Φ1000 | Φ1500 | Φ2000 | Φ2500 | Φ3000 |
| Max. Outflow(m3/h) | 5 | 7.8 | 17.6 | 31.4 | 49 | 70.6 |
| Working Temperature(℃) | 4-50 | 4-50 | 4-50 | 4-50 | 4-50 | 4-50 |
| Filtering Area(m2) | 0.5 | 0.75 | 1.76 | 3.14 | 4.9 | 7.1 |
| Filtering Speed(m/h) | 8-10 | 8-10 | 8-10 | 8-10 | 8-10 | 8-10 |
| Filter Material Height(mm) | 1000 | 1200 | 1200 | 1200 | 1200 | 1200 |
| Diameter*Height(mm) | Φ800*2860 | Φ1012*2897 | Φ1516*3469 | Φ2020*3610 | Φ2524*4020 | Φ3028*4480 |
| Net Weight | 790 | 980 | 1506 | 2455 | 4179 | 6355 |
Customized services are available:
Standard JG wastewater filtration Pressure sand filter treatment capacity is 5-70.6m3/hr, if you need larger treatment, please feel free to contact us, customized product are available.
