MU61A 3 3/4 Digital Multimeter/4000 Counts Digital Multimeter/ Multi Meter/digital Multimeter With Frequency

MU61A 3 3/4 Digital Multimeter/4000 Counts Digital Multimeter/ Multi Meter/digital Multimeter With Frequency thumbnail-1
MU61A 3 3/4 Digital Multimeter/4000 Counts Digital Multimeter/ Multi Meter/digital Multimeter With Frequency photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Model Number:
MU61A
Contact Supplier Request Quote Chat Now
Shanghai MCP Corp.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Model Number MU61A

Feature
.Max. Display 22000
.Capacitor, frequency and temprature measuring
.Max.test voltage up to 1000VDC and 750VAC
.Various kinds of function: auto power off, diode test, triode test, On/Off buzzer, data hold



Technical Data MU61A MU61B
DC voltage
(Range/Accuracy)		 400mV/±(0.8%+3)
4V/40V/400V/±(0.5%+1)
1000V/±(1%+3)		 40mV/±(0.8%+3)
400mV/±(0.8%+3)
4V/40V/400V/±(0.5%+1)
1000V/±(1%+3)
AC voltage
(Range/Accuracy)		 400mV/±(1.2%+5)
4V/40V/400V/±(1%+3)
750V/±(1.2%+5)		 40mV/±(1.2%+5)
400mV/±(1.2%+5)
4V/40V/400V/±(1%+3)
750V/±(1.2%+5)
DC current
(Range/Accuracy)		 400μA/4000μA/±(1%+2)
40mA/400mA/±(1.2%+3)
4A/10A/±(1.5%+3)		 400μA/4000μA/±(1%+2)
40mA/400mA/±(1.2%+3)
4A/10A/±(1.5%+3)
AC current
(Range/Accuracy)		 400μA/4000μA/±(1.2% +5)
40mA/400mA/±(1.5% +5)
4A/10A/±(2% +5)		 400μA/4000μA/±(1.2% +5)
40mA/400mA/±(1.5% +5)
4A/10A/±(2% +5)
Resistance
(Range/Accuracy)		 400Ω/±(1.2% +2)
4kΩ/40kΩ/400kΩ/±(1% +2)
4MΩ/±(1.2% +2)
40MΩ/±(1.5% +2)		 400Ω/±(1.2% +2)
4kΩ/40kΩ/400kΩ/±(1% +2)
4MΩ/±(1.2% +2)
40MΩ/±(1.5% +2)
Temperature
(Range/Accuracy)		 N/A -40°C~-20°C/-(8% +5)
>-20°C~0°C/±(1.2% +4)
>0°C~100°C/±(1.2% +3)
>100°C~1000°C/±(2.5% +2)
Frequency Range 10Hz~10MHz
Accuracy ±(0.1%+4)
Frequency response 45~400Hz
Duty cycle 0.1%~99.9%
Special function
Auto/Manual range √ √
Auto power off √ √
Diode test √ √
On/Off buzzer √ √
EF test √
Triode test √
Max./Min. value display √ √
Simulation bar   √
Auto power off   √
Data hold √ √
Low battery warning √ √
Relatively testing √ √
RS232   √
Input protection √ √
Input resistance 10MΩ
Max.display 4000
Power supply 9V (6F22) battery
Weight (g) 370
Dimensions (W×H×D) 180 × 87 × 47 mm
