SG1641A - Function Generator Frequency Counter
Negotiable
MOQ: 4 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
MCP
Model Number:
SG1641A
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SG1631A - FUNCTION GENERATOR/waveform GeneratorNegotiableMOQ: 2 Pieces -
SG1642C - 5MHz 10Mhz 20MHz FUNCTION GENERATOR / Frequency Generator/sweep Signal GeneratorNegotiableMOQ: 4 Pieces
-
MCP HG2461 I - DDS RF SIGNAL GENERATOR/hf GeneratorNegotiableMOQ: 1 Piece
-
LG1809A - Generator Portable / Digital Audio Signal GeneratorNegotiableMOQ: 6 Pieces
-
LG1809AW - AUDIO GENERATORNegotiableMOQ: 6 Pieces
Place of Origin
Shanghai, China
Brand Name
MCP
Model Number
SG1641A
Specifications
.FUNCTION GENERATOR.Multi waveform:Sine,Square,Triangle and etc.
.Variously output mode CW,FM,Sweep Frequency
SG1641A - FUNCTION GENERATOR
Features
.Apply LSI and MCU
.Multi waveform:Sine,Square,Triangle and etc.
.Variously output mode CW,FM,Sweep Frequency
.DC offset,symmetry continuously adjustable
.Full output protection
.High Reliability:MTBF>10000h
| Technical Data | SG1641A | SG1641B | |
| Main output | Output frequency | 0.1Hz~3MHz | 0.1Hz~10MHz |
| Output waveforms | Sine wave,Square wave,Triangle wave,etc. | ||
| Output impedance | 50Ω | ||
| Output amplitude | 10Vp-p(50Ω)20Vp-p(1MΩ) | ||
| Output attenuation | 0dB/20dB/40dB/60dB | ||
| Symmetry | 20%~80% or 50% | ||
| Sine wave | Distortion factor | ≤1% | |
| Square wave | Rise or fall time | <25ns | |
| TTL output | Rise or fall time | ≤1μs | |
| Low level | ≤0.4V | ||
| High level | ≤3.5V | ||
| Impedance | 600Ω | ||
| Counter | Frequency range | 0.1Hz~50MHz | |
| Input impedance | ≥1MΩ | ||
| Sensitivity | 100mVrms | ||
| Accuracy | 0.1Hz/1Hz/10Hz/100Hz | ||
| Error | ≤0.003%±1 digit | ||
| Max.input voltage | 150V(AC+DC)(with attenuator) | ||
| Input attenuation | 0dB/20dB | ||
| Power supply | 110~127VAC±10%,220~240VAC±10%,50Hz±2Hz/60Hz±2Hz | ||
| Dimension(W×H×D) | 230×80×210mm | ||
| Weight | 1.5kg | ||
