Specifications
16 channel PA-mixing console with very low noise architecture.USB in/out for direct recording to PC
PAN/BAL control
16 channel PA-mixing console with very low noise architecture.
4 subgroups with independent sub-masters
Internal 24bit DSP-effect unit with 100 presets & foot switch
USB in/out for direct recording to PC
12 balanced input channels, 8 Mono + 4stereo:
Input gain
Inserts on mono channels
Peak indication @ -5dB
High pass filter @ 75Hz
3band equalizer with parametric mid
1 AUX send pre (monitoring)
1 AUX send with pre/post switch
EFX send for effects section (post)
PAN/BAL control
Channel mute button
PFL-switch
LEVEL with 60mm fader control
L-R and subgroup 1-2 3-4 select
48V Phantom power on all balanced micros
Use of external effects possible
Balanced Main L/R + subgroup output controls
Headphone and control room output
2x 10section LED VU-meters
7band equalizer on master mix
External power transformer
19" brackets for easy rack mounting included
Technical Information
Max output level (0.5% thd @ 1kHz):
+26dB (MAIN L/R)
+20dB (ALT 3/4, AUX/EFX, CTRL ROOM)
+20dB (INSERT)
More than 100mW (HEADPHONES) @33Ohm
T.H.D:
<0.1% @ +14dB 20Hz~20kHz (MIX L/R, ALT 3/4, AUX/EFX SEND, CTRL ROOM) @10kOhm
Frequency response:
20Hz~20kHz, +1/-2dB (MIX L/R, GROUP 1-2/3-4, AUX1, AUX2/EFX SEND, CTRL ROOM) @10kOhm
Hum and Noise (average Rs=150Ohm):
-127dB equivalent input noise
-95dB residual noise (MIX L/R, GROUP 1-2/3-4, AUX1, AUX2/EFX SEND, CTRL ROOM)
-88dB (MIX L/R, GROUP 1-2/3-4, AUX1, AUX2/EFX SEND, CTRL ROOM) Master fader at nominal level and all channel assign switches off.
