Specifications
P5 LED Video Screen IndoorLED screen China direct manufacturer
Item Name: LED Screen indoor sub SMD 3in1 line
Item no# SLVS2105
SUB SMD Tri-Color (RGB) LED Vision Screen Indoor 3 in 1 line offers most of the advanced features and benefits of the 3 in 1 version.
The main difference between the SUB SMD (3in1 line) screen and the SUB SMD ( 3 in Line) screen is that in the (3 in 1Line) Screen is constructed by lining up the (R, G, B) LED in a line instead of a tight cluster as in the (3in1 line) The main effect difference is in a lower resolution than the 3in1 however the (3 in1 Line) structure offers a different price proposition.
Summit LED Screen Vision Technology can support fron P4 to P12 display indoor solution for out clients.
Features and Benefits
* High Resolution
* High luminance
* Vivid Colors
* Advanced (SMD) Surface Mount Technology
* 3 LED-in-line(R, G, B) Pixel
* Machine Automated and Precision Manufactured
* Precisely Distributed Color and Luminance
* No Pixel Flatness Errors
* Extremely Large Viewing Angles
* No significant color loss from the standard viewing angle
* Reduced Weight
* Modular Design for Easy of Installation
* Modules are constructed into durable structures for ease of installation
....
| Specification: | |
| Item Name | Sub 3on1 P5 Screen |
| Pitch | 5mm |
| Pixel composition | 3in1 line |
| Module resolution(Pixel) | 32*32 |
| Module size(mm) | 160*160mm |
| Cabinet resolution(pixel) | 128*96 |
| Resolution Density | 12288 dots/cabinet |
| Cabinet size | 640*480*141mm |
| Cabinet housing | Aluminum alloy |
| Cabinet weight | 16.5Kg |
| Luminance | |
| Brightness | 2500cd/m2 |
| Physical density(Pixel/m2) | 40000 Pixel/m2 |
| Display Color | 16.7 Million |
| Optimal view distance | ≥6m |
| Peak power consumption | ≤1500W |
| Average power consumption | ≥1150W |
| View angle | Horizontal 120°,Vertical 120° |
| Scan mode | 1/8 |
| Color gradations | 256 Gradations for R,G,B |
| Refresh rate | 400Hz |
| Frame rate | ≥60f/s |
| Control mode | Real time PC to monitor |
| Display ratio | 1027*768;800*600 |
| Drive voltage | 5V~5.5V |
| Blind pixel ratio | <0.001 |
| Operating voltage | 100~240V AC 50~60Hz |
| Effective control distance | ≤130m |
| Working temperature | -10~50 |
| Working humindity | 10%~90% RH |
| Lifespan | ≥100,000hrs |
| IP rating | IP64 |
