Tube Ice Equipment Used in Bars,resorts Ice Using
US$ 1 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Capacity:
2000kg
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Capacity
2000kg
Place of Origin
Guangdong, China
Brand Name
CBFI
Model Number
TV
Ice Shape
Other, TUBE ICE
Voltage
380V/50Hz/3Phase or 220V/60Hz/3Phase or different
Power(W)
7.1kw
Dimension(L*W*H)
1400*1100*1800mm
Weight
1100kg
Certification
CE
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
tube ice equipment1.Tube ice for eating
2.Ice shape : crystal cylinder ice
3.Ice diameter: 22mm, 28mm, 35mm
Newest design tube ice equipment
- Tube ice machine daily capacity from 1 ton to 20 tons.
- Tube ice is a kind of hollow cylindrical ice with external diameter 22mm, 28mm, 35mm and length 25~42mm . The hole diameter is usually 5~10 mm and it can be adjusted according to ice making time.
- Perfect design: adopt 3D simulation assembly, compact structure, easy operate and maintain.
- Health: ice maker adopt SUS 304, PE, and aluminum material to process, and adopt big rounded excessive design, everywhere of the machine is easy to clean
- Fully automatically: PLC system controls the whole ice making process.
- Application: it can be directly eaten or used to freeze drinks, mix wines, cool foodstuffs, make ice pastries and keep fresh ect.
Main model for commercial tube ice machine:
Item No. |
Production |
Compressor Rated Power |
Circulating Water Pump Power |
Cooling Water Pump Power |
Cooling Fan Power |
Ice Cutter Motor Power |
Machine Dimension |
Weight of Machine |
|
Ton/24H |
KW |
KW |
KW |
KW |
KW |
L*W*H |
KG |
TV10 |
1.0 |
3.69 |
0.37 |
1.1 |
0.18 |
0.75 |
1320*950*1800 |
900 |
TV20 |
2.0 |
7.11 |
0.55 |
1.1 |
0.18 |
0.75 |
1400*1100*1800 |
1200 |
TV30 |
3.0 |
9.68 |
0.55 |
1.1 |
0.37 |
0.75 |
1500*1100*1950 |
1500 |
TV50 |
5.0 |
17.47 |
0.55 |
1.5 |
0.75 |
0.75 |
1600*1250*2200 |
1800 |
TV100 |
10.0 |
30.89 |
0.75 |
2.2 |
1.5 |
1.5 |
1700*1300*2200 |
3500 |
TV150 |
15.0 |
42.6 |
1.5 |
2.2 |
2.2 |
1.5 |
3000*1500*2200 |
4250 |
TV200 |
20.0 |
53.2 |
1.5 |
2.2 |
2.2 |
1.5 |
3500*1500*2200 |
6500 |
