Tube Ice Maker*CE approved
*Tube ice is even, smooth and transparent
*Fully automatic
*One cycle-25minutes
Top Supplier of Tube Ice Maker
1. Tube ice
-Tube ice features: tube ice is thick and transparent with long storage period. It isn’t likely to melt in a short time, good air permeability.
-Application: it can be directly eaten or used to freeze drinks, mix wines, cool food stuffs, make ice pastries and keep fresh etc.
-Size: External diameter 22mm, 28mm and 35mm for client's choice.
2. Tube ice machine
-Tube ice machine is machine that produces cylinder edible ice
*Tube ice machine daily capacity: 1ton to 20ton.
-Working condition
*Power supply: standard 380v-50hz-3p. We also can do special power, 220v-50Hz/60hz-3p, 230v-50Hz/60hz-3p, and so on.
*Standard working condition: environment temperature 30°C, water supply temeprautre,23°C, evaporate temperature,-15°C.
*Applicable working condition: environment temperature 5°C ~45°C, supply water 0°C~28°C. It is common that real production of machine will have a little change according to change of water temperature and ambient temperature.
Specially designed ice cutting part and ice oulet
Tube ice machine parameters
tube ice after cut is even, smooth and transparent, good for sale
Tube ice machine evaporator: outside-steel; inside-SS304
Tube ice machine ice making process illustration
World-famous brands for most accessories (easy to find locally): Danfoss expansion valve (Denmark brand)
Danfoss filter-drier (Denmark brand)
Danfoss solenoid valve (Denmark brand) for hot-gas supply
Castel solenoid valve (Italian brand) for liquid supply
If you are interested in our ice machine, pls feel free to send us inquiry. We will reply you within 24hours. Thank you.
In your inquiry, pls tell me:
-What's the daily capacity you need? We can offer from 1ton to 20ton.
-What's the size of tube ice you want? We can offer 22mm, 28mm and 35mm diameter.
-What kind of refrigerant (gas) can be used in your country? R22 or R404A. R22 price is lower than R404A, but R22 is banned in some countries. If R22 can be used in your country, you can choose from R22 or R404A.
-What's your voltage for powering up the machine? 380V-415V/3Phase/50Hz or 220-240V/3Phase/60Hz?
