Help CenterNew Technology Hot Sell Tube Ice Maker (3tons per Day)
Related Products
-
Large Commercial Tube Ice Making Maker (3tons per Day)NegotiableMOQ: 1 Set -
Commercial Tube Ice Maker Match With Ice Bin (3tons per Day)NegotiableMOQ: 1 Set
-
Tube Ice Maker Match With Automatic Ice Outlet (3tons per Day)NegotiableMOQ: 1 Set
-
Commercial Tube Ice Maker Match Using Site (3tons per Day)NegotiableMOQ: 1 Set
-
Commercial Tube Ice Maker (3tons per Day)NegotiableMOQ: 1 Set
Specifications
Tube Ice Maker:1. Compressor: Germany brand Bitzer
2. Tube ice: 22mm, 28mm, or 35mm
3. Ice maker for produce edible ice
TV Series Tube Ice Maker Machine:
Tube ice is a regular cylinder ice that has hollow in the central section of the ice.
The outer diameter is 28mm, 32mm, 35mm, the height can be 30mm to 50mm.
The inner diameter can be adjusted to the time by which the forming of the ice is required.
The tube ice has the advantages of big thickness, good-looking, long-time storage, not easy melting and good permeation.
Mainly used in daily diet, keep fresh for vegetable, fruit and aquatic products.
Tube Ice Maker Machine Models for Reference:
Item No. |
Production |
Compressor Rated Power |
Circulating Water Pump Power |
Cooling Water Pump Power |
Cooling Fan Power |
Ice Cutter Motor Power |
Machine Dimension |
Weight of Machine |
|
Ton/24H |
KW |
KW |
KW |
KW |
KW |
L*W*H |
KG |
TV10 |
1.0 |
3.69 |
0.37 |
1.1 |
0.18 |
0.75 |
1320*950*1800 |
900 |
TV20 |
2.0 |
7.11 |
0.55 |
1.1 |
0.18 |
0.75 |
1400*1100*1800 |
1200 |
TV30 |
3.0 |
9.68 |
0.55 |
1.1 |
0.37 |
0.75 |
1500*1100*1950 |
1500 |
TV50 |
5.0 |
17.47 |
0.55 |
1.5 |
0.75 |
0.75 |
1600*1250*2200 |
1800 |
TV100 |
10.0 |
30.89 |
0.75 |
2.2 |
1.5 |
1.5 |
1700*1300*2200 |
3500 |
TV150 |
15.0 |
42.6 |
1.5 |
2.2 |
2.2 |
1.5 |
3000*1500*2200 |
4250 |
TV200 |
20.0 |
53.2 |
1.5 |
2.2 |
2.2 |
1.5 |
3500*1500*2200 |
6500 |
Machine running condition: water temperature 23°C, evaporate temperature -12°C,condensing temperature 40°C, reference valve under 50Hz power condition. Real production of machine will have a little change according to change of water temperature and ambient temperature.
1. Installation of ice tube machine is easy, only need connect water, power for the machine. All testing work wIill be finished in our factory.
2. Ice making water formed ice in the stainless steel round plate, then, automatically enter into ice falling off procedure, the whole process control by PLC program control, no need people monitor.
3. Evaporator of tube ice machine is round plate type, so, the machine is space save.
4. Ice outgoing automatically, can connect with automatically ice packing machine or converyor belt.
5. All surface that contact with water or ice are stainless steel or other rust-resistant material insured the sanitation of tube ice.
