Specifications
1,Output: 5000KG in 24hours2,Size of ice : 5kg/10kg/20kg.
3,Ice model material: SUS304
4, CE and ISO certificate approved
(1)Industrial ice block making machine structure: Compressor unit, ice making pool and cooling tower-water cooled system(air condenser-air cooled system).It is easy to install, just need to connect the water pipes between the three parts, and supply the power wire to the machine.
(2)Production models: we design the machine in different production models, from 1 ton per day to 100tons per day.
(3)Weight of ice:2.5kg,5kg..10kg..20kg….. also can be done as customers’ requirement.
(4)Power form supply: 380V/50HZ/3P or 230v/60hz/3p.
(5)Refrigerant: we use Freon R22 or R404a
(6)Ice model Material: we use 304 stainless steel or galvanized steel to produce ice cans for block ice machines.
Normal specification:
Ice weight bellows 25kg, we use 1.0mm 304 stainless steel;
Ice weight between 25kg~30kg, we use 1.2mm 304 stainless steel;
Ice weight above 30kg, we use 1.5mm 304 stainless steel or 2.0mm galvanized steel(upon the correct using method, the working life of galvanized steel is 5~6 years. If apply stainless steel, its price is more than 4 times of galvanized steel.)
(7)Application: the block ice is use to reduce temperature, especially in Africa country the power is not stable, when the power is off ,people is the block ice cooling the drinking and beverage, some people the block ice to keep fish fresh or crushed the ice into small pieces to fresh vegetable and fruit.
Ice block making machine models for your reference:
Item No. |
Production |
Rated Power |
Cooling Fan Power |
Machine Dimension |
Weight of Machine |
||
|
Ton/24H |
KW |
KW |
L*W*H |
KG |
||
MB10 |
1.0 |
3.92 |
0.37 |
2820*1410*965 |
900 |
||
MB20 |
2.0 |
7.11 |
0.55 |
1700*750*1500 2220*1440*1065 |
1100 |
||
MB30 |
3.0 |
9.68 |
0.75 |
1800*750*1500 3000*1380*1065 |
1300 |
||
MB40 |
5.0 |
12.56 |
0.75 |
2000*800*1600 3110*1470*1075 |
1500 |
||
MB50 |
8.0 |
14.6 |
1.5 |
2000*800*1600 4560*1380*1150 |
1700 |
||
MB60 |
6.0 |
18.84 |
1.5 |
2000*800*1600 5340*1380*1150 |
1900 |
||
MB80 |
8.0 |
21.30 |
1.5 |
2000*1000*1800 7720*1950*1150 |
2300 |
||
MB100 |
10.0 |
26.60 |
1.5 |
2500*1200*2000 6360*3710*1565 |
2700 |
||
MB150 |
15.0 |
48.30 |
2.2 |
3100*1200*2000 9280*2260*1560 |
3700 |
||
MB200 |
20.0 |
63 |
3.75 |
3500*1500*2200 11560*4200*1565 |
4700 |
||
MB250 |
25.0 |
68.7 |
3.75 |
3500*1500*2200 12080*2260*1560 |
5700 |
||
MB300 |
30.0 |
76.4 |
5.5 |
3500*1500*2200 11560*5430*1600 |
6700 |
||
MB400 |
40.0 |
126 |
7.5 |
2*3500*1300*2200 11560*7080*1600 |
8700 |
||
MB500 |
50.0 |
137.4 |
7.5 |
2*3500*1300*2200 14170*7080*1600 |
10700 |
||
MB1000 |
100.0 |
274.8 |
15 |
4*3500*1300*2200 12000*13500*1450 |
21400 |
||
| |||||||
