MR-C12 Medium-speed Automatic Paper Cup Machine

MR-C12 Medium-speed Automatic Paper Cup Machine thumbnail-1
MR-C12 Medium-speed Automatic Paper Cup Machine photo-1
US$ 16,000 - 17,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Paper Cup Machine
Processing Type:
Other, paper cup forming machine
Contact Supplier Request Quote Chat Now
Pingyang Mingrui Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Product Type Paper Cup Machine
Processing Type Other, paper cup forming machine
Place of Origin Zhejiang, China
Brand Name MingRui
Model Number MR-C12
Voltage 380V 50Hz
Power(W) 7kw
Dimension(L*W*H) 2600mm*1200mm*1700mm
Weight 1500kgs
Certification CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

MR-C12 Medium-speed Automatic Paper Cup Machine

MR-C12 Medium-speed Automatic Paper Cup Machine



Product Description
  1.  Paper cup bottom sealing by Leister hot air system, import from Switzerland.
  2.  It is easy to make cups of different size by changing moulds.
  3.  Cup side sealing by ultrasonic.
  4.  Double PE coating paper cups for cold drink as well as hot drink.
  5.  With our unique original designed bottom knurling system, single shaft, korea type,   this ensures the low leaking ratio and high quality of paper cups.
  6.  Paper sucking system adopt the vacuum pump, big power and stable running.
  7. With unique single shaft design, the drive system is conducted by the stable gear system,  it would be more stable when machine running at a high speed.
  8.  With automatic lubricating system, it will automatic lubricating to every moving parts  when machine runs.



Paper Cup Size 2.5-12 OZ
Speed 70-80pcs/min
Air source 0.4Mpa    0.2m³/min
Raw material  180-350gsm
General power  7kw
Electricity  380V 50Hz
Weight 2500kg
Measurement: 2.6m×1.2m×1.7m



Paper cup production flow chart:



MR-C12 Medium-speed Automatic Paper Cup Machine

MR-C12 Medium-speed Automatic Paper Cup Machine

MR-C12 Medium-speed Automatic Paper Cup Machine



MR-C12 Medium-speed Automatic Paper Cup Machine



Paper cup fan die cutting machine:

MR-C12 Medium-speed Automatic Paper Cup Machine









Packaging & Shipping

 MR-C12 Medium-speed Automatic Paper Cup Machine





Our Services

Best service for you!

Good machine quality!

The machine warranty for one year!



Company Information

Our  factory in Wenzhou Pingyang chouty,China,  specialized in manufacturing automatic web die cutting machine,

creasing die cutting machine, paper fan punching die-cutter and stereo paper box forming machine.



FAQ

Wha't the product time?

Normal about 30days of order 1-5 sets machine.



What's the payment?

TT.30% payment in advance, pay the balance before shipment.

Some country can accept L/C.



What about the shipment?

We can send the machine to the customer  designated locations in China.



After receiving machine, if machine have questions.

We can send engineer to you your country. Customer should pay for engineer and the freight.
