Computer Control Electronical Tensile Universal Testing Machine, 10kN,20kN, 100kN
Main functions
WDW-10 is used for tensile, compression, bending, shearing, peeling, tearing, etc tests of metal and non-metal materials, like rubber, plastic, wire and cable, composite material, metal bar, panel, spring, etc. It confirms to GB, ISO, JIS, ASTM, etc standards, it also supports customized standard. It is an ideal testing machine for quality control enterprise, scientific research department, university and college, etc.
Product feature
a. Computer controlled, load, displacement, extension three closed loop control..
b. Real time displays various testing curve, load-time, load-extension, stress-strain, load-displacement, etc.
c. It includes many kinds of controlling modes, such as constant force, constant displacement, constant deformation, et
d. Control software can automatically figure out tensile strength, yield strength, modulus of elasticity, extend rate after rupture, non-proportional extend strength RP0.2, etc.
e.Testing results can be recorded into Microsoft Word or Excel forms.
f. Testing results can be printed by a HP printer
Main configuration:
- Ø Servo driver: Japanese Panasonic Series
- Ø Servo motor: Japanese Panasonic Series
- Ø Load sensor: High-precision load sensor America Celtron (One)
- Ø Leading screw: precision leading ball screw
- Ø Grips: Tensile grips: flat specimen jaw: 0-7mm, 7-14mm.
Round specimen jaw: φ4mm-φ9mm, φ9mm-φ14mm
Compression grips and Three-point Bending grip.
- Ø Tianchen AD-800 Three closed loop universal testing card (One set in computer)
- Ø Dell computer, 17 inches LCD monitor
- Ø Printer: HP A4 color inkjet printer (One)
- Ø Professional testing software: TENSON universal testing software.
