Manufacturer DT-AS96 AC Ammeter with change over switch
Moving-iron panel Ammeter with a change-over switch is adapted for measuring AC
Ampere in 3 phase 3 wire system and 3 phase 4 wire system. A three-positional switches
installed on the meter frontal side enables the choice of the measured voltage in different
points of the network system.
Moving-iron Voltmeter with a change-over switch is adapted for measuring line-to-line and
phase-to-phase RMS voltage in 3-phase 4-wire power networks. A six(three)-positional
switches installed on the meter frontal side enables the choice of the measured voltage in
six(three) different points of the network system.
Model |
Frame Size (mm) |
Mode |
Measuring Range |
Class Index |
Case Qty.(Pcs) |
AC Ammeter With Change-over Switch ( 2In) | |||||
DT-AS96 |
96X96 |
x/5A* |
5~6000A |
1.5 |
48 |
DT-AS72 |
72X72 |
x/5A* |
5~6000A |
1.5 |
50 |
|
* x/1A upon request. Note: Please mention the No.of positions for the change-over switch. Our standard option is 3 positions: L1-L2,L2-L3, L1-L3. | |||||
AC Voltmeter With Change-over Switch ( 1.2In ) | |||||
DT-VS96 |
96X96 |
- |
100~600V |
1.5 |
48 |
DT-VS72 |
72X72 |
- |
100~600V |
1.5 |
50 |
|
Note: Please mention the No.of positions for the change-over switch. Our standard option is 6positions: L1-L2,L2-L3, L1-L3, L1-N, L2-N, L3-N. | |||||
