Specifications
ncrete compression test machine2.for concrete brick cement compression
3.1 grade
4.CE SGS
Hydraulic rock compression testing machine Concrete compression testing machine supplier Concrete compressive strength test
1.Introduction
Concrete compression testing machine is mainly used for compressive strength test of brick, stone, cement, concrete and other materials.YES series full-automatic Hydraulic rock compression testing machine has adopted universal proportional control valve group, Electro-hydraulic proportional control plate and software, with closed loop control system (Constant acceleration, constant displacement, constant force value) to realize automatic loading via computer.
2.Function and Features
Respect to the force test, the compression testing machine has used USA TRANSCELL main accuracy spokes sensor. The force test accuracy is FS≥0.02%, which enables the force measurement accuracy to reach 1 grade (namely measuring error and the actual value difference is ±1%) within effective test load range.
3.Main Technical parameters
| Model | YES-3000 |
| Maximum test load | 3000kN |
| Effective test load range | 1%-100% of maximum test load, 10kN-1000kN |
| Force measurement accuracy | 1 grade |
| Test force resolution | ±1/300000 of maximum load, internal and external do not divide class, and during whole test resolution unchanged |
| Distance between compression plates | 300mm |
| Compression plates diameter | Φ400mm |
| Piston stroke | 100mm |
| Piston diameter | Φ230mm |
| Maximum oil pressure | 50Mpa |
| Piston speed | 0.5 mm -50mm/min |
| Columns number | 4 columns |
| Distance between columns | 420×420mm |
| Displacement display value accuracy | ≤±1% |
| Deformation test range | 0.1mm-450mm |
| Constant stress control | ≤±1% of set value |
