2000KN Concrete Compressive Strength Testing Machine+Flexural Testing Machine+Cement and Brick Compression Testing Machine
US$ 9,600 - 12,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
TENSON
Model Number:
YES-2000
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic Rock Compression Testing Machine Concrete Compression Testing Machine Supplier Concrete Compressive Strength TestNegotiableMOQ: 1 Set -
Concrete Compressive Strength Testing Machine Hydraulic Press Machine Pressure Testing MachineNegotiableMOQ: 1 Set
-
Hydraulic Compression Testing Machine,Concrete Pressure Test Machine for Cement Concrete BrickUS$ 10,000 - 19,000MOQ: 1 Unit
-
Hydraulic Concrete Compressive Strength Testing Machine Price+hydraulic Press Machine+build Concrete ColumnsUS$ 8,000 - 20,000MOQ: 1 Set
-
YAW-2000B Computerized Electro-hydraulic Press Testing MachineUS$ 13,900 - 16,000MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
TENSON
Model Number
YES-2000
Power
Hydraulic
Usage
Compression Testing Machine
Specifications
Concrete Compressive Strength Testing Machine1.Professional manufacturer
2.Max. load 3000KN,accuracy:0.01KN
2000KN Concrete Compressive Strength Testing Machine+Flexural Testing Machine+Cement Compression Testing Machine
1. Introduction
The machine can test the pressure resistance of cement, concrete and other components and so on. If add the special accessories, it can do the anti-break and anti-pressure tets for building materials and brick. It meets GB/T2611-92,GB/T3722-92 and other test standard, and is executable to GB, ISO, JIS, DIN, ASTM and other international test standard. It applies to quality control department, engineering inspection department, University and college, mining industry and other institution.
2.Main configurations & Features
- This testing machine consists of Load frame, hydraulic pumping station, compression test fixture, electric & hydraulic servo control system, etc.
- Load frame: 4-column frame structure, oil cylinder bottom-mounted. It consists of base, column, cylinder, Load cell, etc.
- High precision load cell to measure load, photoelectrical encoder to measure displacement.
- Hydraulic pump station system: servo pumping station.
- Control system: Full digital hydraulic servo control, which includes load and displacement. PCI measuring & control amplification unit, servo valve driving unit & software system etc. Load and displacement close-loop control. It can complete load speed, displacement speed, load keeping and displacement keeping control modes.
- Computer data processing automatically, the printer can print test report.
3.Main Technical parameters
| Model | FY-1000 |
| Maximum test load | 1000kN |
| Effective test load range | 1%-100% of maximum test load, 10kN-1000kN |
| Force measurement accuracy | 1 grade |
| Test force resolution | ±1/300000 of maximum load, internal and external do not divide class, and during whole test resolution unchanged |
| Distance between compression plates | 300mm |
| Compression plates diameter | Φ400mm |
| Piston stroke | 100mm |
| Piston diameter | Φ230mm |
| Maximum oil pressure | 50Mpa |
| Piston speed | 0.5 mm -50mm/min |
| Columns number | 4 columns |
| Distance between columns | 420×420mm |
| Displacement display value accuracy | ≤±1% |
| Deformation test range | 0.1mm-450mm |
| Constant stress control | ≤±1% of set value |
