BBZ S400 Pipeline Economical Flow and Power Consumption Sensor

BBZ S400 Pipeline Economical Flow and Power Consumption Sensor thumbnail-1
BBZ S400 Pipeline Economical Flow and Power Consumption Sensor thumbnail-2
BBZ S400 Pipeline Economical Flow and Power Consumption Sensor thumbnail-3
BBZ S400 Pipeline Economical Flow and Power Consumption Sensor photo-1
BBZ S400 Pipeline Economical Flow and Power Consumption Sensor photo-2
BBZ S400 Pipeline Economical Flow and Power Consumption Sensor photo-3
US$ 100 - 3,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
BBZ
Model Number:
BBZ S400
Contact Supplier Request Quote Chat Now
Henan BBZ Automation Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Tianjin Lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name BBZ
Model Number BBZ S400
Product Introduction

S400 can be easily detached from the compressed air / gas pipelines to be corrected or

Replaced, The opening may be temporarily closed with a lid

Product features

Easily remove the measuring body and not affected on the measurement pipe.

Stationary applications

Mobile applications

Solutions for large diameter

Product Parameters
Measurement Units
m³/h, m³/min, l/min, cfm, m/s, kg/min, kg/h, kg/s (Reference standards can be set)
Default:
Air: Ps = 1000 hPa, Ts = 20 ° C
Other gases: Ps = 1013 hPa, Ts = 0 ° C
Measuring principle
Thermal Mass Flow
Accuracy
± 2% 0.3% of full scale)
Temperature drift
0.05% / K
Pressure drift
0.5% / MPa
Environmental/ Process Temperature
23 ° C ± 3 ° C
Environmental / Process humidity
<90%, non-condensing
Process pressure
0.6 MPa
Connection
R type thread (ISO 7-1)
Flange EN1092-1, ANSI / B16.5, JIS B2220
Sensor
esistive sensor with glass coated
Measuring medium
Air, N2, O2, Ar, N2O, CO2
Operating temperature
-30 ~50 ° C
-10~50 ° C (with display)
Working pressure
1.6 MPa 4.0 MPa (optional)
Analog output
Signal: 4 to 20 mA
Correspondence: 0 to the maximum range
Accuracy: 0.06 mA
Pulse output
Unit consumption corresponds to a pulse, electrically isolated switching output, high maximum 30 VDC, 20 mA
Power supply
12-30 VDC, 100 mA
Display
128 x 64 pixels, with backlight
Material
Stainless steel 1.4404 (SUS 316L)
Application

Compressed air consumption measurement and costing

Gas leakage detection

Portable measurement on compressed air of a single machine or workshop

Flow measurement of various process gases, such as N 2, CO 2, O 2, Ar, N 2 O

Nitrogen Flow Measurement
